Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YUZUN
-
Model Number:
-
YZ-N612LH22FY
-
Feature:
-
Night Vision
-
Product name:
-
200m laser long range distance 4k ultra hd video security camera 12mp
-
Certificate:
-
ISO9001
-
Color:
-
White
-
Power Supply:
-
AC/ DC 24 V 3A
-
Keyword:
-
200m laser long range distance 4k ultra hd video security camera 12mp
Quick Details
-
Special Features:
-
Human Motion Tracking, NIGHT VISION, Waterproof / Weatherproof
-
Function:
-
Two-way Audio, PAN-TILT, RESET, NIGHT VISION, Waterproof / Weatherproof
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YUZUN
-
Model Number:
-
YZ-N612LH22FY
-
Feature:
-
Night Vision
-
Product name:
-
200m laser long range distance 4k ultra hd video security camera 12mp
-
Certificate:
-
ISO9001
-
Color:
-
White
-
Power Supply:
-
AC/ DC 24 V 3A
-
Keyword:
-
200m laser long range distance 4k ultra hd video security camera 12mp
200m laser long range distance 4k ultra hd video security camera 12mp
12mp security camera
security camera 12mp
4k ultra hd video
| Model |
YZ-N612LH22FY (12MP) |
|
Video and audio |
|
|
Video compression |
H.264/H.265 High Profile @Level 4.0 |
|
Main processor |
32bit dual core high performance DSP |
|
Image sensor |
1/1.7” CMOS |
|
Effective pixels |
12 mega pixels |
|
Maximum resolution |
First stream:4000*3000 |
|
Second stream:1920*1020 |
|
|
Third stream:704*576 |
|
|
Video frame rate |
First stream:4000*3000@20fps |
|
Second stream:1920*1080@25fps |
|
|
Third stream:704*576@25fps |
|
|
Horizontal resolution |
≥2000TVL |
|
Video bit rate |
0.1Mbps-10Mbps adjustable |
|
Video stream |
Three bit stream design, output multi-channels max resolution video at the same time in max 20fps bite rate, 1-20fps adjustable |
|
Camera module |
|
|
Focal length |
6.5mm~143mm(F1.5~F3.4) |
|
Zoom |
22x optics |
|
Min. illumination (LUX) |
Color : 0.025/F1.5 ; Monochrome : 0.0025/F1.5 ; IR : 0 |
|
Electronic shutter |
Auto / manual , 1/6-1/8000s |
|
White balance |
Automatic white balance / manual |
|
Zoom mode |
Motorized zoom , auto focus |
|
3D noise reduction |
Support |
|
Low illumination enhanced |
Support IR-CUT auto switch |
|
Wide dynamic |
Support |
|
Function |
|
|
Rotation range |
Horizontal : 0~360°;vertical:0~90° |
|
Rotation speed |
Horizontal : 0~350°/s;vertical:0~90°/s |
|
Preset point |
256 |
|
Linear scanning |
3 lines |
|
Trajectory |
Maximum record and demonstration 4 groups of trajectory of scanning path, maximum including 100 actions for each group |
|
PTZ function |
Humanization focus, automatic speed matching function, power outage memory function |
|
Wiper |
Call wiper function by setting preset point |
|
Network |
|
|
Network protocols |
IPv4 , TCP/IP , UDP , HTTP , RTP/RTCP/RTSP , FTP , UPnP , DDNS , NTP , IGMP , ICMP ; |
|
Access protocol |
Standard ONVIF2.0 protocol |
|
Safety |
Password protection , multi-user access , access authorized |
|
IE application |
Support web configuration , support OSD character overlay , channel title and time information |
|
System integration |
|
|
APP interface |
Support integrated API,SDK |
|
IR distance |
Built-in 8 pieces of matrix infrared light and 4 pieces laser IR light, infrared servo, group , zoom tracking, the distance up to200M |
|
Network interface |
1 RJ45 10Base-T/100Base-TX |
|
Other |
|
|
Power supply |
AC/ DC 24 V 3A |
|
Power consumption |
<60W |
|
Working environment |
Working temperature -35℃~+55℃(heater activated -40℃-+50℃);working humidity ≤ 90% |
|
Housing |
Aluminum alloy die casting |
|
IP rating |
IP66 |
|
Dimension (mm) |
No package: Φ350*240, Package: Φ 510*320*320 |
|
Weight |
No package : 5.3 kg, Package : 6.56 kg |
|
Installation |
Wall mounted , hang mounted |
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
5-30 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
