eco solvent printer double head print and cut eco solvent printer a3

eco solvent printer double head print and cut eco solvent printer a3

FOB Reference Price: Get Latest Price

≥1 Sets

US $7900

≥10 Sets

US $6000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Ink Type:: water-based, Eco-solvent ink

Place of Origin:: Guangdong, China

Brand Name:: Disen

Voltage:: 220V/110V(optional)

Dimensions(L*W*H):: 1970*700*1140mm

Weight:: 125 KG

Name:: print and cut eco solvent printer

Print Head:: DX5 / DX7

Number of nozzles:: 1 pcs

Print Resolution:: 720DPI / 1080DPI / 1440DPI

Ink dot type:: Gray scale variation points

LCD display panel:: LCD display& soft panel operating of computer

Max weight of media:: Less than20kgs/roll

Cartridge capacity:: Standard 220ml/ color

Quick Details

Print Dimension:: 960mm, Other, 914mm

Condition:: New

Color & Page:: Multicolor

Ink Type:: water-based, Eco-solvent ink

Place of Origin:: Guangdong, China

Brand Name:: Disen

Voltage:: 220V/110V(optional)

Dimensions(L*W*H):: 1970*700*1140mm

Weight:: 125 KG

Name:: print and cut eco solvent printer

Print Head:: DX5 / DX7

Number of nozzles:: 1 pcs

Print Resolution:: 720DPI / 1080DPI / 1440DPI

Ink dot type:: Gray scale variation points

LCD display panel:: LCD display& soft panel operating of computer

Max weight of media:: Less than20kgs/roll

Cartridge capacity:: Standard 220ml/ color

Product Description

Model	PC-500	PC-750		PC-900		PC-1600
Print Head	E-PSON DX5 / DX7 1print head
Maximum Print Width	500mm	730		914mm		1520mm
Print Resolution	720DPI / 1080DPI / 1440DPI
Ink dot type	Gray scale variation points
Speed and yield	1 print head
	3PASS	19 m2/h		4PASS		15 m2/h
	6PASS	10 m2/h		8PASS		7.6 m2/h
Ink type	Water-based dyes, water-based paint, Eco-solvent ink
Ink color	4 colors, CMYK
Ink Supply System	Cartridge Ink Supply System, continuous ink system for optional accessories
Cartridge capacity	Standard 220ml/ color;		Standard 220ml X 2 / color
Media Type	PP synthetic paper,Gloss photo paper,PVC,Car Stickers,Label,Vinyl sticker,light sheet, Printable Flex, PU heat transfer vinyl.
Way of loading media	Standard loading without power
Max weight of media	Less than20kgs/roll
Height of print head frame	1mm-6mm height of print head is adjustable 1mm-6mm
Print head cleaning system	Auto cleaning system with anti-clogged flash spray & auto moisturizing function
Media heating system	3 section constant temperature heating system from front& back bedplates, temperature adjustable
Drying system	Standard cold air configuration, PTC hot air (optional accessories)
LCD display panel	LCD display& soft panel operating of computer
Data interface	USB2.0 interface (Window2000,NT,XP etc) USB2.0 (Window2000,NT,XP etc)
RIP software	Standard Flexi SIGN-PRO 10.5.1 RIP Photo printer
Cutting system	ROLAND blade;cutting force:0-300g ; speed:0-400mm/s
Repeat accuracy (cutting)	±0.1mm or less ±0.1mm
Power supply	AC110 or 220V,50HZ/60HZ
Operating environment	Temperature:20℃ ~ 28℃ Humidity:40% ~ 70%
NW/GW(kgs)	82KG/140KG	90KG/150KG			125KG/180KG	140KG/225KG
*Machine size(LWH)*	1450x665x354mm	1690665mm354mm			19707001140	2570700mm1140mm
*Packing size(LWH)*	1570x740x550mm	1810740550			2120* 770* 740mm	2720* 770* 830mm

Detailed Images

Enterprise Show

Related Products

Print head type: E-pson DX5/DX7 print head
Ink type: water-based dyes, water-based pigments, weak solvent inks
Applicable printing materials: self-adhesive vinyl, body sticker, cold lamination film, banner, paper, film, linoleum and thermal transfer paper, etc.print and cut eco solvent printer,eco solvent printer double head print and cut,eco solvent print and cut printer,print and cut eco solvent printer a3.
product description
1. Multifunctional printing and cutting machine, which can complete color printing and cutting along the line at one time;print and cut eco solvent printer,eco solvent printer double head print and cut,eco solvent print and cut printer,print and cut eco solvent printer a3.
2, widely used in label printing and printing samples, wall labeling, identification production, personalized body stickers output, clothing shoes and hats personalized production areas;
3.Easy-to-use, flexible function, multi-purpose machine, more efficient and convenient, can be used in all aspects, serving advertising and signage companies, label printing companies, and clothing production enterprises;
4, support a variety of image formats and software such as JPG / TIFF / AI / PNG / EPS and so on.
Product advantages
1. It integrates inkjet printing and digital cutting functions;
2. Comes with powerful and easy-to-use Flexisign-PRO RIP software;
3, four-color printing;
4, models include PC-500 / 750/900/1600; printing width from 500mm, 730mm, 914mm, 1600mm to meet different customer needs;eco solvent printer plotter 3d plotter large format eco solvent printer
5. Supports separate printing, contour cutting and cutting while printing modes, multiple uses of one machine;
6, can choose a variety of different cutting knife and height adjustment to match the different thickness of the medium;eco solvent printer print and cut,eco solvent printer cut,eco solvent printer and cut,solvent printer cut,eco solvent print and cut printer.
7. It can meet contour cutting, make cutting data based on pictures, use cutting puzzle function to cut long materials such as block cutting, and simultaneously realize printing and cutting functions
8, can use a variety of PVC stickers, paper stickers and other stickers.
Product application areas: digital printing equipment, clothing printing supplies, ball service numbers, personalized T-shirt patterns, casual clothes, names, LOGO production, etc.print and cut eco solvent printer,eco solvent printer double head print and cut,eco solvent print and cut printer,print and cut eco solvent printer a3.
