Model
|
Reference output (voltage and current)
|
|
Application certification and dimensions
|
24W side insert series
Model: J301C
|
12V2A 12V1.5A 5V4A 9V2A 5V3A ...
Output parameters: Voltage: 4.5-30V
Current: 0.1-4.0A
|
|
Applicable fields:Luminaire, LED strip, monitor, massager, DC fan, Router, beauty instrument
Certification: CCC/CE/UL/PSE/KC
Safety standard: UL62368ETL1310 EN62368 En61558 GB4943 GB4706
Pin specifications: China, USA, Japan,
EuropeShell
size: L68.98*W41.5*H28.98mm
|
24-40W interchangeable foot series
Model: JZB024
|
5V4A 12V1.5A 12V2A 12V2.5A 12V3A 24V1A 24V0.5A ...
Output parameters: Voltage: 4.5-48V Current: 0.1-4A
|
|
Applicable fields:Indoor surveillance, wall mounted video recorder, massager, camera, display, beautyinstrument, massager, speaker, lamp
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 EN61558 GB4943 GB4706
Pin specifications: China, United States, United Kingdom, Australia,Japan, Korea, Europe, India, Taiwan
size: L71*W44.4*H29mm
|
36-48W interchangeable foot series
Model: J361
|
5V5A 12V3A 12V3.5A 12V4A ,15v3a 24V2A ...
Output parameters: Voltage: 4.5-48V Current: 0.1-5A
|
|
Applicable fields:Network red live light, laser hair removal machine motor fan, light belt, outdoor
monitoring car water cup, fast cooling cup, billboard, alarm, cabinet light
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 EN61558 GB4943 GB4706
Pin specifications: China, United States, United Kingdom, Australia,Japan, Korea, Europe, India, Taiwan
size: L89.4*W47.4*H32.5mm
|
48-72W interchangeable foot series
Model: J651
|
5v6a 12v4a 12v5a 12v6a 24v3a 20v3a 36v2a 19v3.42a 19v4.73a...
Output parameters: Voltage: 4.5-48V Current: 0.1-6A
|
|
Applicable fields:Water purifier, LCD monitor, water pump, energy storage, shared power bank, video recorder,massager, laptop
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 EN61558 GB4943 GB4706
Pin specifications: China, United States, United Kingdom, Australia,Japan, Korea, Europe, India, Taiwan
size: L107.8*W50.7*H33mm
|
36W Series desktop
Model: J024
|
5V4A 12V1.5A 12V2A 12V2.5A 12V3A 24V1A 24V0.5A 15V2A...
Output parameters: Voltage: 4.5-48V Current: 0.1-4A
|
|
Applicable fields:Indoor surveillance, wallmounted video recorder, massager, camera, display, beautyinstrument, massager,speaker, lamp
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 En61558 GB 4943 GB4706
Desktop model: figure-eight end
size: L91.4*W44.9*H30mm
|
36W series wall insert type
Model: J024
|
5V4A 12V1.5A 12V2A 12V2.5A 12V3A 24V1A 24V0.5A 15V2A...
Output parameters: Voltage: 4.5-48V Current: 0.1-4A
|
|
Applicable fields:Indoor surveillance, wallmounted video recorder, massager, camera, display, beautyinstrument, massager,speaker,
lamp
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 En61558 GB4943 GB4706
Pin specifications: China, United States, United Kingdom, Australia, Japan, Korea, Europe, India, Germany
size: L71.4*W44.4*H30mm
|
48W series wall insert type
Model: J361
|
5V5A 5V6A 12V3A 12V3.5A 12V4A ,15v3a 24V2A ...
Output parameters: Voltage: 4.5-48V Current: 0.1-6A
|
|
Applicable fields:Network red live light, laser hair removal machine motor fan, light belt, outdoor
monitoring car water cup, fast cooling cup, billboard, alarm, cabinet light
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard:UL62368 ETL1310 EN62368 En61558 GB4943 GB4706
Pin specifications: China, United
States, United Kingdom, Australia, Japan, Korea, Europe, India, Germany
size: L89.4*W47.4*H32.5mm
|
48W series desktop
Model: J361
|
5V5A 5V6A 12V3A 12V3.5A 12V4A ,15v3a 24V2A ...
Output parameters: Voltage: 4.5-48V Current: 0.1-6A
|
|
Applicable fields:Network red live light, laser hair removal machine motor fan, light belt, outdoor
monitoring car water cup, fast cooling cup, billboard, alarm, cabinet light
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ ETL/UKCA/SAA/BIS
Safety standard:UL62368 ETL1310 EN62368 En61558 GB4943 GB4706
Tail seat: eight-character tail plum blossom tail product tail
size: L100.4*W46.8*H32.5mm
|
72W series wall insert
Model: J651
|
5v6a 12v4a 12v5a 12v6a 24v3a 20v3a 36v2a 19v3.42a 19v4.73a...
Output parameters: Voltage: 4.5-48V Current: 0.1-6A
|
|
Applicable fields:Water purifier, LCD monitor, water pump, energy storage, shared power bank, video recorder,massager, laptop
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 EN61558 GB4943 GB4706
Pin specifications: China, United States, United Kingdom, Australia,Japan, Korea, Europe, India, Taiwan
size: L109.45*W50.7*H33mm
|
72W Series desktop
Model: J651
|
5v6a 12v4a 12v5a 12v6a 24v3a 20v3a 36v2a 19v3.42a 19v4.73a...Output parameters: Voltage: 4.5-48V
Current: 0.1-6A
|
|
Applicable fields:Water purifier, LCD monitor, water pump, energy storage, shared power bank, video recorder,massager, laptop,Docking station
Certification:UL/CE/PSE/GS/BS/CQC/KC/CCC/ETL/UKCA/SAA/BIS
Safety standard: UL62368 ETL1310 EN62368 EN61558 GB4943 GB4706
Tail seat: eight-character tail plum blossom tail product tail
size: L114.4*W50.9*H32.5mm
|
30W square shell
Model: J303
|
12V2A 24V1A 15V2A 12V1.5A 5V4A 9V3A 9V2A ...
Output parameters: Voltage: 4.5-48V Current: 0.1-4A
|
|
Applicable fields:Smart home, digital, desk lamp, security, medical
Certification:UL/CCC/CQC/CE/GS/PSE/FCC/SAA/UKCA
Safety standard: UL62368 ETL1310 EN62368 EN61558 GB4706 GB4943
Output Pin specifications:China, United States, United Kingdom, Australia, Japan, Europe
(Folding foot 8-figure tail fixed foot converter)
size: L57.1*W57.1*H30mm
|
48W square shell
Model: J483
|
5V5A 5V6A 12V3A 12V3.5A 12V4A ,15v3a 24V2A ...
Output parameters: Voltage: 4.5-48V Current: 0.1-6A
|
|
Applicable fields:Live fill light, energy storage, projector, LED nail light therapy machine, LED light with lightbox, monitoring
Certification:UL/CCC/CQC/GS/CE/PSE/FCC/SAA/UKCA
safety standards: GB4706 UL62328 GB4943
ETL1310 EN62368 EN61558
Pin specifications: China, United States, United Kingdom,Australia, Japan, Europe
(Folding foot 8-figure tail fixed foot converter)
size: L63.3*W63.3*H31.55mm
|
72W square shell
Model: J653
|
5v6a 12v4a 12v5a 12v6a 24v3a 20v3a 36v2a 19v3.42a 19v4.73a...
Output parameters: Voltage: 4.5-48V Current: 0.1-6A
|
|
Applicable fields:Laptop, smart monitor, lithium battery, water pump, printer, water dispenser, LED light strip,water purifier
Certification:UL/CCC/CQC/GS/CE/PSE/FCC/SAA/UKCA
safety standards: GB4706 UL62328 GB4943
ETL1310EN62368 EN61558
Pin specifications: China, United States, United Kingdom,Australia, Japan, Europe
(Folding foot 8-figure tail fixed foot converter)
size: L75.3*W72.3*H31.4mm
|
130W/200W desktop
Model: J130 J200
|
24V5A 24V6A 12V8A 12V10A 24V8A 19V6A 24V7A 12V9A
Output parameters: Voltage: 9-56V Current: 0.1-10A
|
|
Applicable fields:Dryers, motors motors,LED lights, printers, display screens, water purifiers, medical devices, push-rods
Certification:CCC/COC/CE/UL/PSE/UKCA/SAA/GS/KC/ETL
safety standards: UL62368 ETL1310 EN62368 En61558 GB4943 GB4706
Desktop specifications: eight-character tail product tail plum blossom tail
size: L156.05*W65.1*H33.5mm
|
