Quick Details
-
Model Number:
-
STC-8000H
-
Front panel size:
-
75*34.5(mm)
-
Mounting size:
-
71*29(mm)
-
Product size::
-
63.8*35*85mm
-
Sensor wire length:
-
2(m)(include probe)
-
Power supply:
-
220VAC+10%/~15% 50/60Hz
-
Operating ambient temperature::
-
- 30 °C ~ 80 °C
Quick Details
-
Warranty:
-
other
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Elitech
-
Model Number:
-
STC-8000H
-
Front panel size:
-
75*34.5(mm)
-
Mounting size:
-
71*29(mm)
-
Product size::
-
63.8*35*85mm
-
Sensor wire length:
-
2(m)(include probe)
-
Power supply:
-
220VAC+10%/~15% 50/60Hz
-
Operating ambient temperature::
-
- 30 °C ~ 80 °C
1.Application
For a variety of freezer, drinks libraries, library of high temperature, cooling equipment and single controlled environment.
2. The main features
Refrigeration, frost, fan output control
Way back to the temperature control temperature, the user menu and managers set respectively
Frost, fan a variety of optional management mode
3. Dimension
Installation dimensions: 71*29mm
Product size: 63.8*35*85mm
Specifications and technical parameters:
The whole machine size: 77.0 * 34.5 * 34.5 (unit: mm)
Mounting holes size: 70.5 * 28.5 (unit: mm)
Operating ambient temperature: - 30 °C ~ 80 °C
Relative humidity: no more than 85% (not condensation)
