Quick Details
-
Brand Name:
-
E-Weichat
-
Model Number:
-
EW-M2068S-4T
-
External Size:
-
131x92x37mm
-
Keywords:
-
ip68 waterproof junction box
-
Certificate:
-
SAA,TUV, CE,RoHS
-
Connector Color:
-
Black
-
Operating Rating:
-
-40℃ - +105℃
-
Ampere/Voltage:
-
32A/450V
-
Outer Cable Diameter:
-
M20:5-9mm;9mm-12mm/M25:5-9mm;9mm-12mm,10-14mm
-
Wire Section:
-
0.5mm2-6.0mm2
-
Housing:
-
94V-2
-
IP Code:
-
IP68
-
Connector Material:
-
PA66 & Copper Alloy
Quick Details
-
Protection Level:
-
IP68
-
Type:
-
Junction Box
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
E-Weichat
-
Model Number:
-
EW-M2068S-4T
-
External Size:
-
131x92x37mm
-
Keywords:
-
ip68 waterproof junction box
-
Certificate:
-
SAA,TUV, CE,RoHS
-
Connector Color:
-
Black
-
Operating Rating:
-
-40℃ - +105℃
-
Ampere/Voltage:
-
32A/450V
-
Outer Cable Diameter:
-
M20:5-9mm;9mm-12mm/M25:5-9mm;9mm-12mm,10-14mm
-
Wire Section:
-
0.5mm2-6.0mm2
-
Housing:
-
94V-2
-
IP Code:
-
IP68
-
Connector Material:
-
PA66 & Copper Alloy
Product Description
Specification
|
Item
|
EW-M2068S-4T
|
|
Number of Poles
|
4T
|
|
Operating current
|
40A
|
|
Operating voltage
|
450V
|
|
Wire cross-section
|
0.5mm2-6.0mm2
|
|
Operating rating
|
-40℃-105℃
|
|
Connector housing Cable gland
|
PA66 UL94-V2
|
|
Sealing
|
Silicone
|
|
Materials properties
|
Halogen Free
|
|
Contacts
|
Nickel-plated Brass
|
|
Protection against solid/water (IP)
|
IP68(4m, 365 days)
|
|
Certifications
|
TUV/SAA/CE/LVD
|
|
Cable Diameter min-max
|
M20:5-9mm;9mm-12mm/M25:5-9mm;9mm-12mm,10-14mm
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
