Quick Details
-
Warranty:
-
25years
-
Brand Name:
-
QJPV
-
Model Number:
-
QJM550-144HDG
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
2279*1134*30mm
-
Maximum Power Voltage(Vmp):
-
42.13V
-
Maximum Power Current(Imp):
-
13.05A
-
Open Circuit Voltage(Voc):
-
49.80V
-
Short Circuit Current(Isc):
-
13.97A
-
Maximum System Voltage:
-
1500V
-
Power Tolerance:
-
±5W
-
Operating Temperature:
-
-40℃~+85℃
-
STC:
-
1000W/m2, AM1.5, 25℃
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black
-
Panel Efficiency:
-
21.4%
-
Warranty:
-
25years
-
Brand Name:
-
QJPV
-
Model Number:
-
QJM550-144HDG
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
2279*1134*30mm
-
Maximum Power Voltage(Vmp):
-
42.13V
-
Maximum Power Current(Imp):
-
13.05A
-
Open Circuit Voltage(Voc):
-
49.80V
-
Short Circuit Current(Isc):
-
13.97A
-
Maximum System Voltage:
-
1500V
-
Power Tolerance:
-
±5W
-
Operating Temperature:
-
-40℃~+85℃
-
STC:
-
1000W/m2, AM1.5, 25℃
|
Mechanical Specifications
|
|
|
Model Number
|
QJM550-144HDG
|
|
Place of Origin
|
China
|
|
Cell size
|
182*182mm
|
|
Cell Number
|
144(6*24)
|
|
Type
|
Perc half-cell, high-efficient bifacial monocrystalline module
|
|
Panel Dimension (H/W/D)
|
2279x1134x30mm
|
|
Weight
|
32kg
|
|
Front Cover
|
Tempered AR coated glass,2.0mm
|
|
Frame
|
Anodized Aluminium Alloy
|
|
Junction Box
|
IP 68,3 diodes
|
|
Protection Class
|
ClassII
|
|
Cables&Plug Connectors
|
300mm,4mm2&MC4 compatible;customized
|
|
Panel Efficiency
|
21.40%
|
|
Certificate
|
TUV&CQC&CE
|
|
Warranty
|
Material and process warranty for 12 years, power warranty for 25 years
|
|
Maximum Series Fuse Rating
|
30A
|
|
Maximum System Voltage
|
1500V
|
Q1: Do your company a trading company or manufacturer?
A1: QJPV is a Group Company which have solar panel factory and solar system factory.We also do Construction Engineering. Solar industry is our main products for exporting.
Q2: How long can you delivery my order?
A2: Usually we need 15 days to prepare your order after receiving the deposit..
Q3: Can you do OEM for me?
A3: Yes, We can accept OEM, If the quantity is small, Carton factory don't accept to OEM the carton, if quantity not so big, We can make sticker OEM, if you need one full container, Both Carton and sticker we can OEM for you.
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5: What is your factory capacity ?
A5: Our factory capacity is 1.9GW Per year, We also do OEM for Tier 1 brands .
Q6: What is solar panel warranty ?
A6: 12 years limited product warranty, 30 years output performance warranty .
Q7: Can the products pricing be cheaper?
A7: Of course, you will be offered a a very good discount with large quantities.
A1: QJPV is a Group Company which have solar panel factory and solar system factory.We also do Construction Engineering. Solar industry is our main products for exporting.
Q2: How long can you delivery my order?
A2: Usually we need 15 days to prepare your order after receiving the deposit..
Q3: Can you do OEM for me?
A3: Yes, We can accept OEM, If the quantity is small, Carton factory don't accept to OEM the carton, if quantity not so big, We can make sticker OEM, if you need one full container, Both Carton and sticker we can OEM for you.
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5: What is your factory capacity ?
A5: Our factory capacity is 1.9GW Per year, We also do OEM for Tier 1 brands .
Q6: What is solar panel warranty ?
A6: 12 years limited product warranty, 30 years output performance warranty .
Q7: Can the products pricing be cheaper?
A7: Of course, you will be offered a a very good discount with large quantities.
Q8 : How can we guarantee the products quality？
A8 : Always provide the esteemed buyer a pre-production sample before mass production ; Always testing every product before despatching the shipments.
A8 : Always provide the esteemed buyer a pre-production sample before mass production ; Always testing every product before despatching the shipments.
