Quick Details
-
Output Power:
-
7kW/11kW
-
Input Voltage:
-
230V / 400V±20%
-
Data protocol:
-
OCPP 1.6J & 2.0.1
-
Model:
-
7kW/11kW
-
Current:
-
32A, 16A
-
Voltage:
-
230V / 400V±20%
-
AC plug type:
-
Type-2 plug or Type-2 socket
-
Network connection:
-
Ethernet, WiFi,Bluetooth
-
Protection:
-
IP55
-
Efficiency:
-
≥94%
-
Color:
-
White, Black, Blue, Red, Orange, Green
-
Certificate:
-
CE, IEC 61851-1, IEC 62196-2
Quick Details
-
Place of Origin:
-
Fujian
-
Model Number:
-
IOCAH15
-
Brand Name:
-
iocharger
-
Output Power:
-
7kW/11kW
-
Input Voltage:
-
230V / 400V±20%
-
Data protocol:
-
OCPP 1.6J & 2.0.1
-
Model:
-
7kW/11kW
-
Current:
-
32A, 16A
-
Voltage:
-
230V / 400V±20%
-
AC plug type:
-
Type-2 plug or Type-2 socket
-
Network connection:
-
Ethernet, WiFi,Bluetooth
-
Protection:
-
IP55
-
Efficiency:
-
≥94%
-
Color:
-
White, Black, Blue, Red, Orange, Green
-
Certificate:
-
CE, IEC 61851-1, IEC 62196-2
Product Advantages
Products Description
Specification
|
Model
|
IOCAH15-7S / IOCAH15-7T
|
IOCAH15-11S / IOCAH15-11T
|
|
|
Application
|
Residental
|
|
|
|
Voltage and Wiring
|
Single Phase 230V
|
Three Phase 400V
|
|
|
Frequency (Hz)
|
50/60Hz
|
|
|
|
Current Output
|
Single Phase 32A Max
|
Three Phase 16A Max
|
|
|
Charging Connector
|
Type-2 Socket or Type-2 Tethered 5m
|
|
|
|
RCD
|
30mA AC & 6mA DC
|
|
|
|
Electrical Protection
|
Over current, Under voltage,
Over voltage, Over temperature,
Surge protection, Short circuit, Ground fault
|
|
|
|
Button
|
1 x Physical Button
|
|
|
|
Indicators
|
Standby(Blue), Charging(Flashing Green), Fault(Red), Warning(Flash Red)
|
|
|
|
Network Connectivity
|
Ethernet/ WiFi/
Bluetooth
|
|
|
|
Data Protocol
|
OCPP1.6J, OCPP2.0.1, ISO15118 Plug & Charge
|
|
|
|
DLB
|
Dynamic Load Balancing
|
|
|
|
Operation Temp.
|
-30 °C ~ 50 °C / -22 °F ~ 122 °F
|
|
|
|
Storage Temp.
|
-40 °C ~ 70 °C / -40 °F ~ 158 °F
|
|
|
|
Working Humidity
|
5%~95% without condensation
|
|
|
|
Mounting Type
|
Wall Mounted (default) / Floor post (optional accessory)
|
|
|
|
Ingress Protection
|
IP55
|
|
|
|
Mobile App
|
iOS/Android
|
|
|
|
Certificate
|
CE, IEC 61851-1, IEC 62196-2
|
|
|
