•It can adopt different types of pre-made pouches,such as Flat pouch, Stand-up pouch, Zipper pouch, Spout pouch, M gusset pouch,
Paper pouch, Aluminium foil pouch, etc.
- Product Details
- {{item.text}}
Quick Details
-
Weight (KG):
-
1500
-
Voltage:
-
220/380VCustomized
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Haiyi
-
Dimension(L*W*H):
-
2000x1830x1440
-
Machine Material:
-
#304 stainless steel
-
Working station:
-
8
-
Filling range:
-
5-1500g
-
Product name:
-
Premade Bags Packing Machine
-
Main Function:
-
Weighing Filling Sealing
-
Keyword:
-
Powder Doypack Packing Machine
-
Automaticity:
-
Touch Screen Control
-
Advantage:
-
Stable Operation
-
Optional Devices:
-
zipper open devices
-
Pouch type:
-
Ziplock Doypack
Quick Details
-
Function:
-
FILLING, Sealing, coding
-
Packaging Type:
-
Stand-up Pouch, Bags, Film, Foil, Pouch, case
-
Packaging Material:
-
Plastic, Paper, Wood
-
Weight (KG):
-
1500
-
Voltage:
-
220/380VCustomized
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Haiyi
-
Dimension(L*W*H):
-
2000x1830x1440
-
Machine Material:
-
#304 stainless steel
-
Working station:
-
8
-
Filling range:
-
5-1500g
-
Product name:
-
Premade Bags Packing Machine
-
Main Function:
-
Weighing Filling Sealing
-
Keyword:
-
Powder Doypack Packing Machine
-
Automaticity:
-
Touch Screen Control
-
Advantage:
-
Stable Operation
-
Optional Devices:
-
zipper open devices
-
Pouch type:
-
Ziplock Doypack
Application
GRANULES TYPE
•Block material:fish boll,candy,red jujube,cereal,peanut,daily necessities,puffed food,etc. •Granules:granular drugs,
capsules,seeds,coffee bean,nuts,fertilizers,hardware,etc.
capsules,seeds,coffee bean,nuts,fertilizers,hardware,etc.
POWDERS TYPE
•Wide application:It adopt different types of powder.
•Powder type:milk powder, seasoning, coco milk, pesticide, washing powder, flour, etc.
LIQUID/PASTE TYPE
•Wide application:It adopt different types of liquid and paste
•Liquid/paste type:hand washing gel,soy,beverage,peanut butter,chili sauce,hotpot sauce,etc.
POUCH TYPE
Products Description
|
MODEL
|
HY8-200
|
HY-260
|
HY-300
|
||
|
Pouch Size(mm)
|
W:80-200
L:100-400
|
W:140-260
L:100-400
|
W:180-300
L:100-400
|
||
|
Filling Range
|
10-1500g
|
|
10-2500g
|
||
|
Packing Speed(pouch/min)
|
25-60
|
25-55
|
10-35
|
||
|
Air Consumption
|
≥0.6m³/min(supply by user)
|
|
|
||
|
Power
|
3.6kw
|
|
4kw
|
||
According to your material and pouch type ,we can add some other function.
Horizontal Pouch Feeder,Pouch-bottom Virbration,Powder Deduster, Zipper Closed,Nitrogen Filling,Making Hole,etc.
Machine Details
Touch Screen
Vertical Type Premade Pouch Magazine
Date Coder
Pouch-top Open Device
Heat Sealing Bar
Output Conveyor
|
Main Components and Parts List
|
|
|
|
Name
|
Place of Origin or Brand
|
|
|
PLC
|
Germany SIEMENS
|
|
|
Touch Scree
|
Germany SIEMENS
|
|
|
Frequency Inverter
|
China AETLA
|
|
|
Magnetic Valve
|
Germany FESTO
|
|
|
Vacuum Valve
|
Germany FESTO
|
|
|
Vacuum Filter
|
China AETLA
|
|
|
Vacuum Pump
|
China YUNWANG
|
|
|
Cylinder
|
China AETLA
|
|
|
Encoder
|
Japan Omron
|
|
|
Bearing
|
Germany IGUS
|
|
|
We offer medium and hi-grade equipment sets to meet a variety of market demands.
The brand can be configured according to your requirements |
|
|
