1. Speed up to 3000BPH for 750ml/bottle
2. Photoelectric sensors and servo-driven
3. No un-filling and mis-filling
4. Filling volume ranges from 100ml to 5000ml.
5. Accurancy +/– 0.1%
6. Lobe Pump for high viscous liquid filling
7. Easy to clean & no wearing parts 8. Bottle size recipe memory 9. User friendly
- Product Details
- {{item.text}}
Quick Details
-
Filling Accuracy:
-
≥ 99.7%
-
Applicable Industries:
-
Food industry, daily chemical industry, cosmetics industry, medical industry, pesticide industry, household industry
-
Voltage:
-
380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KinYo
-
Dimension(L*W*H):
-
2260*1110*2320
-
Weight:
-
1000 KG
-
Product name:
-
Filling machine
-
Material:
-
304/316 Stainless Steel
-
Filling speed:
-
90 Bottles for 750ml size in 1min
-
Filling volume:
-
20ml to 5000ml
-
Filling nozzles:
-
2
-
Control:
-
PLC
-
Add-ons:
-
Heating, cleaning, etc
-
Power supply:
-
Customized
Quick Details
-
Machinery Capacity:
-
6000BPH
-
Packaging Material:
-
Plastic, Metal, Glass
-
Filling Material:
-
Beer, Milk, Water, Oil, Juice, Other
-
Filling Accuracy:
-
≥ 99.7%
-
Applicable Industries:
-
Food industry, daily chemical industry, cosmetics industry, medical industry, pesticide industry, household industry
-
Voltage:
-
380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KinYo
-
Dimension(L*W*H):
-
2260*1110*2320
-
Weight:
-
1000 KG
-
Product name:
-
Filling machine
-
Material:
-
304/316 Stainless Steel
-
Filling speed:
-
90 Bottles for 750ml size in 1min
-
Filling volume:
-
20ml to 5000ml
-
Filling nozzles:
-
2
-
Control:
-
PLC
-
Add-ons:
-
Heating, cleaning, etc
-
Power supply:
-
Customized
P
roduct designation
2 pcs of filling nozzles fill 3000 bottles per hour while 4 pcs of filling nozzles fill 6000 bottles per hour neverthless more cost-effective
K
ey Merits
Lobe pump outsells piston pump for high viscous liquid filling
Merits:
P
roduct Details
Bought-in parts are sorted into high-end and low-end to meet your differed requirements.
|
Servo Motor
|
Panasonic
|
Filling volume
|
20ml-5000ml
|
|
Rotary Lobe Pump
|
OuMing(China)
|
Power
|
4.7kW
|
|
Switch
|
Schneider
|
Qty. of servo motor
|
6
|
|
Touchscreen
|
XinJie(China)
|
Container width
|
50mm-160mm
|
|
PLC
|
XinJie(China)
|
Container height
|
60mm-300mm
|
|
Pneumatic Components
|
SMC
|
Contianer neck diameter
|
Over 10mm
|
|
Photoelectric Sensor
|
Autonics
|
Total length of conveyor
|
4m
|
|
Ball Screw
|
HIWIN
|
Dimension
|
2260*1110*2320mm
|
|
Qty. of filling nozzles
|
2
|
Package size
|
2300*1100*2050mm
|
P
roduct Application
Wide application in
household industry
1. Chemical industry:
AES, LAS, AOS, MES, K12, glycerin, sorbitol, fatty alcohol, shower gel, pomade,
viscous toner,
skin cream(
Body lotion
), shampoo, hand soap, toothpaste, liquid soap, laundry detergent, dye, pigment, various slurry , chemical additives, adhesives, silicone oil, leather oil, various colloidal materials,
petrol engine oil,
etc.
2. Food:
Chocolate, honey, sucrose, tomato juice, concentrated juice, jam, ice cream, yeast slurry, meat slurry, jelly, condiments, lees, soy protein, flour slurry
, mayonnais, bechamel, ketchup, pesto, gastrique, coulis, mustard, mayonnalse, syrup,
glycerinum,
dressing and paste
3. Dairy:
Milk, cream, butter, yogurt, cheese, yogurt.
4. Papermaking
Polyacrylamide (PAM), calcium carbonate, starch paste, carboxylated styrene-butadiene latex, rosin, rosin gum, pulp, filler, dry strength agent, wet strength agent, sizing agent, retention and drainage aid, defoamer , coating, water treatment chemicals, etc.
5. Chemical fiber
Viscose pulp porridge, PVA, vinylon pulp, acrylic pulp, urethane pulp, polyester chips, polyester, polypropylene, man-made fibers, functional fibers, etc.
6. Medicine:
Various ointments, extracts, medicine emulsions, pill pastes, syrups, health products, pharmaceuticals, etc.
7.Coatings:
Paints, coatings, inks, insulating paints, resins, additives, organic solvents, etc.
