Quick Details
-
Brand Name:
-
unionfiber
-
Use:
-
ftth
-
Warranty Time:
-
10 years
-
Product name:
-
Mini PLC Optical Splitter
-
Fiber Type:
-
SM G652D
-
Ports:
-
2 Ports
-
Application:
-
FTTH, FTTB, FTTO, FTTx
-
Connector:
-
UPC
-
Connector Type:
-
SC
-
Length:
-
1M/2M/3M...customize
-
Color:
-
White, Blue
-
Operating temperature:
-
-40~+85
Quick Details
-
Type:
-
PLC splitter
-
Model Number:
-
1*2 Mini PLC Optical Splitter
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
unionfiber
-
Use:
-
ftth
-
Warranty Time:
-
10 years
-
Product name:
-
Mini PLC Optical Splitter
-
Fiber Type:
-
SM G652D
-
Ports:
-
2 Ports
-
Application:
-
FTTH, FTTB, FTTO, FTTx
-
Connector:
-
UPC
-
Connector Type:
-
SC
-
Length:
-
1M/2M/3M...customize
-
Color:
-
White, Blue
-
Operating temperature:
-
-40~+85
Product Description
|
Parameter
|
|
Unit
|
Unit
|
1×2
|
1×4
|
1×8
|
1×16
|
1×32
|
1×64
|
|||||||||
|
Fiber Type
|
|
|
|
G.657A, or customized
|
|
|
|
|
|
|||||||||
|
Operating Wavelength
|
|
nm
|
nm
|
1260~1650
|
|
|
|
|
|
|||||||||
|
Insertion Loss
|
p
|
Max
|
dB
|
4.0
|
7.0
|
10.4
|
13.5
|
16.8
|
20.5
|
|||||||||
|
|
s
|
Max
|
dB
|
4.2
|
7.3
|
10.6
|
13.8
|
17.1
|
20.8
|
|||||||||
|
PDL
|
|
Max
|
dB
|
0.2
|
0.3
|
0.3
|
0.3
|
0.3
|
0.5
|
|||||||||
|
Loss Uniformity
|
|
Max
|
dB
|
0.6
|
0.8
|
1.0
|
1.4
|
1.6
|
2.0
|
|||||||||
|
Return Loss
|
|
Min
|
dB
|
55(P Grade)/50(S Grade)
|
|
|
|
|
|
|||||||||
|
Directivity
|
|
Min
|
dB
|
55
|
|
|
|
|
|
|||||||||
|
Operating Temperature
|
|
℃
|
|
-40 ~ +85
|
|
|
|
|
|
|||||||||
|
Storage Temperature
|
|
℃
|
|
-40 ~ +85
|
|
|
|
|
|
|||||||||
|
Dimension(L×W×H)
|
|
|
mm
|
130×100×25
|
|
|
130×100×50
|
130x100x102
|
130x100x206
|
|||||||||
|
Remark:
The above parameters do not include connectors; If connectors are added, the insertion loss will increase 0.2dB each. |
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
1.Uniform light distribution The signal can be evenly distributed to users
2. New upgrade chip,Quality Assurance Stable performance
3.This product is made of new ceramic insert with excellent performance, stability and durability
4. Low insertion loss,High back reflection Low polarization dependent loss
1.Advanced production and testing equipment.
2.Professional manufacturer, 100% tested.
3.Full compliance with ISO 9001:2008 quality management system.
4.Our company has experienced professional team.
5.Provide reliable solutions and satisfactory services.
6.Warmly services with careful attentions.
7.Can provide your specific inquiry within 24 hours.Advanced production and testing equipment.
WeUnion Communication Technology Co., Ltd. is a professional manufacturer focuses on development,production, and sales of fiber telecommunication product. We provide Fiber Optic Cable, Fiber Patch cord, fiber pigtail, Optic PLC splitter, Fiber Distribution Boxes and relevant products which are widely used in FTTX, LAN, WAN, G-Pon, E-Pon Project. Our company has advance production and test equipments, strict production and quality control system, and stable supply chain. We are fully compliant with ISO9001: 2008 quality management system, we guarantee that our products areIEC60794 and Telcordia-GR-326-Core standard compliant, also compliant with our customers’ varied requirements.
Our company has rich experienced professional team and iscommitted to providing customers with reliable solution and satisfactory services. Through continuous development and expansion of our company, we now have customer around the world, especially in North America, South America, Europe, andAsia. Our products and services have been well received by customers.
In the future, we will continue to provide customerswith safe and reliable FTTX solutions.
Q1: When can I get the quotation back?
A:Generally, quotes will be replied within 24 hours or faster(weekends not included), however, a few of days would be taken for special ones.
Q2:How about the cable's quality ?
A: Our factory has dug in this industry for many years and sold to many countries in the world. We are fully compliant with ISO9001: 2008 quality management system, we guarantee that our products are IEC60794 and Telcordia-GR-326-Core standard compliant. We have a series of professional equipment and manufacturing instruments to make sure reliable quality of our products.
Q3: How do l assure that you are a reliable supplier?
A: We are the Assessed Supplier of Alibaba.com. Alibaba as the third party to verify our factory and office to confirm we are a real and reliable supplier. If you are willing to verify that through the phone or video, you are welcome at any time.
Q4: Could the OEM be accepted and what's the MOQ?
A: Of course, your customization order is always welcomed. The MOQ Depends on different
