- Product Details
- {{item.text}}
Quick Details
-
Max. Resolution:
-
203 dpi
-
Brand Name:
-
YoucTech
-
Model Number:
-
YCP-588
-
Place of Origin:
-
Fujian, China
-
Product name:
-
mini portable receipt thermal printer
-
Print method:
-
Thermal line printing
-
Printing Speed:
-
50~90mm/s
-
Printing Resolution:
-
203DPI (8 dots/mm)
-
Printing width:
-
48mm (384 dots/line)
-
Paper Type:
-
Thermal paper
-
Paper width:
-
58mm
-
Paper Thickness:
-
0.06~0.08mm
-
Paper Roll diameter:
-
40mm
-
Color:
-
Black, Blue
Quick Details
-
Max Paper Size:
-
58mm
-
Black Print Speed:
-
50~90mm/s
-
Color Print Speed:
-
NA
-
Max. Resolution:
-
203 dpi
-
Brand Name:
-
YoucTech
-
Model Number:
-
YCP-588
-
Place of Origin:
-
Fujian, China
-
Product name:
-
mini portable receipt thermal printer
-
Print method:
-
Thermal line printing
-
Printing Speed:
-
50~90mm/s
-
Printing Resolution:
-
203DPI (8 dots/mm)
-
Printing width:
-
48mm (384 dots/line)
-
Paper Type:
-
Thermal paper
-
Paper width:
-
58mm
-
Paper Thickness:
-
0.06~0.08mm
-
Paper Roll diameter:
-
40mm
-
Color:
-
Black, Blue
Printing Resolution 203dpi 2 Inch 58mm Mobile Receipt Thermal Printer For Fuel Dispenser
|
Model
|
YCP-588
|
|
|
|
Printing
|
Method
|
Thermal line printing
|
|
|
|
Speed
|
50~90mm/s
|
|
|
|
Resolution
|
203DPI (8 dots/mm)
|
|
|
|
width
|
48mm (384 dots/line)
|
|
|
Paper
|
Type
|
Thermal paper
|
|
|
|
width
|
58mm
|
|
|
|
Thickness
|
0.06~0.08mm
|
|
|
|
Roll diameter
|
40mm
|
|
|
Reliability
|
TPH
|
50km
|
|
|
Interface
|
Standard
|
BT2.0/4.0+USB
|
|
|
Cutting type
|
Manual
|
Tear bar
|
|
|
Character size
|
ANK Character, Font A: 12*24 dots
Font B: 9*17 dots Simplified/Traditional: 24*24 dots |
|
|
|
Barcode type
|
UPC –A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODEBAR/CODE39/CODE93/CODE128/ITF, QR code
|
|
|
|
Logo download
|
Support logo，jpg download tool software
|
|
|
|
Printing command
|
ESC/POS command
|
|
|
|
Driver available
|
Windows98/2000/2003/XP/Vista/Linux/7
|
|
|
|
Sensor
|
Paper End Sensor, Mark Sensor
|
|
|
|
Power supply
|
External 12V/2A power adapter
|
|
|
|
|
Rechargeable Ni-NH 7.2V NiMh, 2600mAh
|
|
|
|
Color
|
Black, Blue
|
|
|
|
Outline dimension
|
105(L)*78(W)*47(H)mm
|
|
|
|
Accessories
|
Paper manual, interface cable, power cable, power plug, paper roll
|
|
|
|
After-sales service
|
12 months warranty
|
|
|
Q1. Samples and MOQ?
A:1pcs acceptable.
Q2. Payment terms?
A:We accept EXW,FCA,FOB,CIF,CNF,DAP,DDP etc.
Q3.How do I install the printer?
A: An user manual/CD driver is included in the printer packing. You can operate by the guidiance.
Q4. Print languages supported in your printers?
A:48 differentlanguages print are supported. You can check with us before order.
Q5.Warranty and after-sale service?
A:12 months warranty. Free spares will be offered for replacement during warranty peroid.Technical and after-sale service are always available to any questions relating to software and printing operations.
