Connector Plug Test Equipment Insertion Extraction Force Tester Automatic Insertion Force Testing Machine

Connector Plug Test Equipment Insertion Extraction Force Tester Automatic Insertion Force Testing Machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $3200

≥10 Sets

US $1900

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Determination of load:: 50kg, 20kg, 5kg, 2kg

Decomposition capacity:: ≥ 0.01kg

Measurement height:: within 150 mm

The test speed range:: 0~300mm/min

Number of tests:: 0-9999999

X, Y axis travel range:: 0~75mm

Transmission mechanism:: ball screw

Appearance size:: 360*260*940mm

Weight:: 67kg(machine)

Power supply:: AC110V or 220V

Quick Details

Warranty:: 1 Year

Place of Origin:: Hebei, China

Brand Name:: btutest

Determination of load:: 50kg, 20kg, 5kg, 2kg

Decomposition capacity:: ≥ 0.01kg

Measurement height:: within 150 mm

The test speed range:: 0~300mm/min

Number of tests:: 0-9999999

X, Y axis travel range:: 0~75mm

Transmission mechanism:: ball screw

Appearance size:: 360*260*940mm

Weight:: 67kg(machine)

Power supply:: AC110V or 220V

Automatic insertion force testing machine

The simple plugging force testing machine is suitable for the plugging force test of various mobile phones and computer peripheral connectors, this machine can solve the fixture problems of various connectors, and the male and female connectors can be automatically aligned during the test, and there will be no unilateral problem.

Specification

Determination of load 50kg, 20kg, 5kg, 2kg Decomposition capacity: ≥ 0.01kg Measurement height within 150 mm The test speed range is 0~300mm/min Number of tests: 0-9999999 X, Y axis travel range 0~75mm Transmission mechanism ball screw Appearance size: 360260940mm Weight: 67kg(machine) Power supply AC110V or 220V Test items Connector single-hole plugging test, connector whole row plugging test, connector single PIN and plastic retention test, general compression, tensile failure test

Product Description

Performance benefits

this machine can solve the fixture problems of various connectors, and the male and female connectors can be automatically aligned during the test, and there will be no unilateral problem.
