Quick Details
-
Application:
-
LANDSCAPE
-
Product Weight（kg）:
-
0.5
-
Input Voltage(V):
-
24V
-
CRI (Ra>):
-
90
-
Lamp Luminous Flux(lm):
-
670
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Wilgex
-
Model Number:
-
WJ-PNF-D18-RGB-D-24V
-
Emitting Color:
-
Dynamic Pixel RGB
-
LED Light Source:
-
Epistar SMD 5050
-
LED Quantity:
-
112 LEDs with 16 ICs
-
Size:
-
Round dia 18mm
-
Material:
-
PVC+Copper Wire
-
Voltage:
-
24V
-
Max loading length:
-
20m by one side power feeded or 40m by both sides power feeded
-
Control system:
-
SPI WS2811 DMX512
-
IP Grade:
-
IP65
-
Package:
-
50m per roll per carton
Quick Details
-
Color Temperature(CCT):
-
Dynamic Pixel RGB
-
Warranty(Year):
-
3-Year
-
Lamp Body Material:
-
PVC
-
Application:
-
LANDSCAPE
-
Product Weight（kg）:
-
0.5
-
Input Voltage(V):
-
24V
-
CRI (Ra>):
-
90
-
Lamp Luminous Flux(lm):
-
670
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Wilgex
-
Model Number:
-
WJ-PNF-D18-RGB-D-24V
-
Emitting Color:
-
Dynamic Pixel RGB
-
LED Light Source:
-
Epistar SMD 5050
-
LED Quantity:
-
112 LEDs with 16 ICs
-
Size:
-
Round dia 18mm
-
Material:
-
PVC+Copper Wire
-
Voltage:
-
24V
-
Max loading length:
-
20m by one side power feeded or 40m by both sides power feeded
-
Control system:
-
SPI WS2811 DMX512
-
IP Grade:
-
IP65
-
Package:
-
50m per roll per carton
Reliability Test
|
TEST CATEGORY
|
TEST ITEMS
|
STANDARD/VALUE
|
|
Optical Test
|
Spectrum Analysis
|
IES LM 79(CCT,lumen, CRI, SDCM,XY,wavelength)
|
|
|
Photometric Distribution
|
IES LM 79(lumen intensity distribution &Lux diagram)
|
|
|
Lumen Maintenance & Lifetime
|
IES LM84&IES TM 28
|
|
Temperature Test
|
Nomal Temperature Test-25℃
|
UL1598&UL2388&IEC60598-1&IEC60598-2-21
|
|
|
Abnormal Operation Test-70℃
|
UL1598&UL2388&IEC60598-1&IEC60598-2-21
|
|
Physics Test
|
Bending Test
|
Manufacturer-defined, 1000 cycles
|
|
|
Swing Test
|
UL2388,>750 cycles
|
|
|
Tensile Test
|
Manufacturer-defined,>the weight of light in max.
running length by double ends feed
|
|
|
Twist Test
|
Manufacturer-defined, 200 cycles
|
|
|
IK08
|
IEC62262
|
|
|
BallImpact
|
UL1598&UL2388&IEC60598-1&IEC60598-2-21
|
|
Weathering Test
|
Swimming Pool Water Immersion Test
|
GB9667,PH6.8-7.6, free chlorine 0.3-0.6mg/L
|
|
|
Sea Water Immersion Test
|
IEC60598-1,Salinity 4%
|
|
|
Salt Spray Test
|
IEC68-2-11
|
|
|
Outdoor Exposure
|
Manufacturer-defined
|
|
Environment Test
|
Flame Resistant Test
|
UL94
|
|
|
UV Exposure Test
|
ASTMG154, UVA@340nm
|
|
|
IPX5 IPX6 IPX7IPX8
|
IEC60529
|
|
|
Temperature Shock Test
|
Manufacturer-defined,-40℃-60℃(typical temperature range)
|
|
|
Constant Temperature Test
|
Manufacturer-defined,70℃(typical temperature range)
|
