Quick Details
-
Brand Name:
-
Sanco
-
Model Number:
-
ES090-20/35/50mm²
-
Terminal material:
-
Copper Alloy, Silvering-plated
-
Plugging times:
-
200
-
Multiple Polarization:
-
6 Keys
-
Rated Current:
-
120A-25mm² /150A-35mm²/200A-50mm²
-
Rated Voltage:
-
DC 1500V /AC 800V
-
Resistance and Withstand Voltage:
-
AC 3000V
-
Insulation Resistance:
-
≥500MΩ
-
Temperature Rise:
-
<50K
-
Protection grade:
-
IPXXB IPX7
-
Certification:
-
EN 61984(TUV) ; UL 1977
Quick Details
-
Application:
-
Power
-
Gender:
-
Female
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sanco
-
Model Number:
-
ES090-20/35/50mm²
-
Terminal material:
-
Copper Alloy, Silvering-plated
-
Plugging times:
-
200
-
Multiple Polarization:
-
6 Keys
-
Rated Current:
-
120A-25mm² /150A-35mm²/200A-50mm²
-
Rated Voltage:
-
DC 1500V /AC 800V
-
Resistance and Withstand Voltage:
-
AC 3000V
-
Insulation Resistance:
-
≥500MΩ
-
Temperature Rise:
-
<50K
-
Protection grade:
-
IPXXB IPX7
-
Certification:
-
EN 61984(TUV) ; UL 1977
Specification
|
item
|
value
|
|
Model Number
|
ES090
|
|
Color
|
Black, Orange
|
|
Terminal material
|
Copper Alloy, Silvering-plated
|
|
Plugging times
|
200
|
|
Multiple Polarization
|
6 Keys
|
|
Rated Current
|
120A-25mm²/150A-35mm²/200A-50mm²
|
|
Rated Voltage
|
DC 1000V/AC 800V
|
|
Resistance and Withstand Voltage
|
AC 3000V
|
|
Insulation Resistance
|
≥500MΩ
|
|
Temperature Rise
|
<50K
|
|
Ambient temperature
|
-40℃~+125℃
|
|
Certification
|
EN 61984(TUV); UL 1977
|
