Quick Details
-
Brand Name:
-
WENBA
-
Model Number:
-
TNS-30Kva
-
Capacity:
-
30Kva
-
Input Voltage:
-
280V- 430V or 304V-456V
-
Output Voltage:
-
3 phase 380v
-
Efficiency:
-
≥95%
-
Frequency:
-
50/60Hz
-
Ambient Temperature:
-
-10℃~+40℃
-
Protection:
-
Over/Under Voltage, Short Circuit, Over Temperature, Phase Failu
-
Delay time:
-
3-7S short time dealy
-
Certificate:
-
CE
-
Warranty:
-
18 Months
Quick Details
-
Phase:
-
Three Phase
-
Current Type:
-
AC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WENBA
-
Model Number:
-
TNS-30Kva
-
Capacity:
-
30Kva
-
Input Voltage:
-
280V- 430V or 304V-456V
-
Output Voltage:
-
3 phase 380v
-
Efficiency:
-
≥95%
-
Frequency:
-
50/60Hz
-
Ambient Temperature:
-
-10℃~+40℃
-
Protection:
-
Over/Under Voltage, Short Circuit, Over Temperature, Phase Failu
-
Delay time:
-
3-7S short time dealy
-
Certificate:
-
CE
-
Warranty:
-
18 Months
Key attributes
Industry-specific
attributes
|
Phase
|
|
Three Phase
|
|
|
|||
|
Current Type
|
|
AC
|
|
|
|||
|
Place of Origin
|
|
Zhejiang, China
|
|
|
|||
|
Brand Name
|
|
Wenba or your own OEM Logo
|
|
|
|||
|
Model Number
|
|
TNS-30KVA
|
|
|
|||
|
Usage
|
|
To stabilize the input voltage automatically
|
|
|
|||
|
Item name
|
|
Voltage Regulator/Stabilizer/AVR
|
|
|
|||
|
Capacity
|
|
30KVA
|
|
|
|||
|
Input voltage
|
|
280-430V
|
|
|
|||
|
Output voltage
|
|
380V
|
|
|
|||
|
Efficiency
|
|
≥95%
|
|
|
|||
|
Response Time
|
|
≤1 S
|
|
|
|||
|
OEM/ODM
|
|
Yes/Available/OK Spannungsstabilisator
|
|
|
|||
|
After sale service
|
|
Yes/Available Stabilizuesi i tensionit
|
|
|
|||
|
Protection
|
|
Over/Under Voltage, Short Circuit, Over Temperature,etc
|
|
|
|||
Packaging & delivery
|
Package Type:
|
|
|
Strong plywood case.
|
|
|||
Supply Ability
|
Supply Ability
|
|
30000 Set/Sets per Month
|
|
|
|||
Video
Description
You are here:Home>>
Voltage Regulator/Stabilizers
>>TND/SVC Voltage Regulator/Stabilizers
Product Description
* When grid voltage instability,automatically sampling control circuit sends a signal to drive servo motor
* Waveform distortionless, reliable performance,long-term operation
* Over voltage, under voltage protected function
|
Specification
|
|
TNS-30KVA
|
|
|
|||
|
Input Voltage
|
|
280V-430V/304V-456V
|
|
|
|||
|
Output Voltage
|
|
380V
|
|
|
|||
|
Output Deviance
|
|
1-3%(Adjustable)
|
|
|
|||
|
Frequency
|
|
50/60Hz
|
|
|
|||
|
Efficiency
|
|
≥95%
|
|
|
|||
|
Response Time
|
|
≤1S
|
|
|
|||
|
Ambient Temperature
|
|
-10℃~+40℃
|
|
|
|||
|
Insulation Resistance
|
|
≥5MΩ
|
|
|
|||
|
Overload
|
|
Double Reted Current,One Min
|
|
|
|||
|
Waveform Distortion
|
|
Non-Lack Fidelity Wareform
|
|
|
|||
|
Protect
|
|
Overvoltage,Overcurrent,Lack Phases
|
|
|
|||
|
Trade Items
|
|
|
|
|
||||
|
MOQ
|
1 Set
|
|
|
|
||||
|
Design Ability
|
OEM&ODM is welcome,can supply sample
|
|
|
|
||||
|
Certification
|
CCC,CE,ISO9001,ISO14001,SGS
|
|
|
|
||||
|
Packing
|
Standard Export Packing
|
|
|
|
||||
|
Payment Term
|
Trade Assurance,T/T,L/C,D/A,D/P Western Union MoneyGram and so on
|
|
|
|
||||
|
Delivery time
|
7-10 working days after payment received
|
|
|
|
||||
|
Model
|
Weight (KG)
|
Outline (L*W*H, CM)
|
QTY
|
|
TNS-6 K
|
24.5
|
36*27.5*68
|
1
|
|
TNS-9 K
|
30
|
39*32*78
|
1
|
|
TNS-15 K
|
38
|
44.5*36*78
|
1
|
|
TNS-20 K
|
49
|
52*39.5*85.5
|
1
|
|
TNS-30 K
|
72
|
52*39.5*85.5
|
1
|
|
TNS-40 K
|
133.5
|
65.5*54*117.5
|
1
|
|
TNS-50 K
|
144
|
65.5*54*117.5
|
1
|
|
TNS-60 K
|
161
|
65.5*54*117.5
|
1
|
|
TNS-80 K
|
186.5
|
65.5*54*117.5
|
1
|
|
TNS-100 K
|
236.5
|
76*63*129
|
1
|
