Quick Details
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
540mm*540mm(Folded), 2285mm*540mm(Open)
-
Panel Efficiency:
-
21%
-
Cell Type:
-
Mono cells
-
Pm:
-
200W
-
Vmp/Voc:
-
19.8V/23.7V
-
Imp/Iso:
-
10.1A/11.1A
-
Dimension:
-
540mm*540mm(Folded), 2285mm*540mm(Open)
-
Front side material:
-
ETFE/Frosted PET
-
Cloth:
-
900D fabric, optional color
-
Connector:
-
MC4/DC pin/Anderson/USB...
-
Maximum System Voltage:
-
700V
-
Maximum Series Fuse Rating:
-
20A
Quick Details
-
Color:
-
Customize
-
Brand Name:
-
Sunfield
-
Model Number:
-
SFED-Z200M
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
540mm*540mm(Folded), 2285mm*540mm(Open)
-
Panel Efficiency:
-
21%
-
Cell Type:
-
Mono cells
-
Pm:
-
200W
-
Vmp/Voc:
-
19.8V/23.7V
-
Imp/Iso:
-
10.1A/11.1A
-
Dimension:
-
540mm*540mm(Folded), 2285mm*540mm(Open)
-
Front side material:
-
ETFE/Frosted PET
-
Cloth:
-
900D fabric, optional color
-
Connector:
-
MC4/DC pin/Anderson/USB...
-
Maximum System Voltage:
-
700V
-
Maximum Series Fuse Rating:
-
20A
Product Description
Specification
|
MONO/POLY
|
Mono
|
|
Item No.
|
SFED-Z200M
|
|
Cell brand
|
Hetero junction Cells
|
|
Maximum power (Wp)
|
200
|
|
Maximum power voltage (V)
|
17
|
|
Maximum power current (A)
|
11.76
|
|
Open circuit voltage (V)
|
20
|
|
Short circuit current (A)
|
12.7
|
|
Cell efficiency (%)
|
≥23%
|
|
Number of solar panel (Pcs)
|
4*54W
|
|
Folded size (mm)
|
540*540
|
|
Open size (mm)
|
2320*540
|
|
Front side material
|
PET or ETFE
|
|
Cloth color
|
Black/Grey/Camouflage...
|
|
Grommets
|
Φ6mm/8mm/10mm
|
|
Junction Box
|
Optional
|
|
Connector
|
MC4/DC pin/Anderson/USB...
|
|
Maximum System Voltage
|
700V
|
|
Maximum Series Fuse Rating
|
20A
|
|
Temperature Range
|
-40---+85℃
|
|
Power guarantee
|
5 years for the whole products, 90% power for 5 years, 80% power for 10 years.
|
|
Certificate
|
CE, ISO9001-2015, RoHS, UKCA
|
Product Details
Remark: Connectors can be customized with MC4, USB, Anderson, DC Pin in different dimensions according to clients' needs;
Accessories can also be customized according to clients' needs.
Product Features
1) Small Volume. Compact
into a kit, easy to store and carry.
2) Large Range of Output Power. From 14 to 300Watts of output power, to power variety applications.
3) Multiple interfaces. To work for multiple devices, like mobile, iPad, batteries or power stations, ect.
4) Water-resistant & durable: Made of durable Oxford water resistant cloth, it is ideal for outdoor activities such as camping, climbing, hiking, picnic...
5) Durable solar panels with PCB back sheet, no glass, no frame.
6) Made by high efficiency Hetero-junction/PERC/SunPower solar cells, the efficiency can reach 24% max.
7) Foldable and portable: It is convenient to carry wherever you go. It can be folded into a briefcase for easy transport. You can enjoy solar energy by placing the panel outside of your bag, absorbing solar energy while hiking or camping.
Installation Instructions
Product Applications
Applications
Portable foldable solar panels can be widely used in car, electric vehicles, RVs, yachts, backpacks, tents, lamps and other fields as long as there is sunshine, you can use it.
