HPC600 HPC601 Portable Diesel Vehicle Automobile Exhaust Gas Smoke Opacity Meter

HPC600 HPC601 Portable Smoke Opacimeter Diesel Vehical Handheld Smoke Opacity Meter

Main features:
Split structure design, more convenient operation, more accurate data;
Large-screen LCD display, full Chinese menu operation;
Using split-flow sampling technology, the smoke can be measured when the diesel vehicle accelerates, decelerates and stabilizes;
The data is automatically linearized, and the opacity N, light absorption coefficient K and the corresponding filter paper smoke value Sf can be displayed;
Use "air curtain" technology to protect the optical system from pollution;
Automatic temperature control in the testing room can prevent condensation and affect the test accuracy;
With automatic time display;
Equipped with built-in automatic printer or Blue-tooth, RS232 interface;
License plate number input and 500 sets of data storage, reference function, clock display
Equipped with test channels for speed and oil temperature;
Meet the requirements of ISO116614, GB3847-2018, GB36886-2018, JJG976-2010.

Main technical parameters:

Oil temperature: 0-150℃
Indication error ≤±2% (measured value)
Stability Automatic zero calibration, torque drift ≤±1%/4h
Repeatability Repeat error≤±1%
Resolution N is 0.1%, K is 0.01m-1, RPM is 10rpm, OIL TEMP is 0.1℃
Output mode LCD display, printer can be attached to print smoke density (maximum darkness), instant curve, test time,
Date etc. An interface can be attached to connect to a computer network.
The temperature of the measuring room is 70℃ (automatic constant temperature). When the temperature error is ≥±10%, the temperature and error indicator lights are on
Environmental conditions Temperature -5~50℃, relative humidity ≤90%
Power AC100-240V 50/60Hz or DC12V (optional power inverter) Power consumption 150VA
Dimensions Control unit 240mm (length) × 310mm (width) × 170mm (height)
(Including bracket) Measuring unit 130mm(length)×400mm(width)×390mm(height)
Weight: control unit 4kg
measuring unit 5kg
