Quick Details
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
GuangXi, China
-
Brand Name:
-
Shenniao
-
Model Number:
-
light steel keel
-
Product name:
-
light steel keel
-
Material:
-
Aluminum Alloy 6063-T6
-
Keyword:
-
Hot Dipped Galvanized Grating
-
Usage:
-
Wall
-
Size:
-
Customized Size
-
Thickness:
-
Custom:3-10mm Routine Use:3mm 4mm 5mm
-
Width:
-
50mm/65mm/70mm/90mm/100mm
-
MOQ:
-
Accept Samples
-
Packing:
-
Standard Sea Worthy Packing
-
Payment term:
-
30%TT Advance + 70% Balance
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Inspection, Free spare parts
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
GuangXi, China
-
Brand Name:
-
Shenniao
-
Model Number:
-
light steel keel
-
Product name:
-
light steel keel
-
Material:
-
Aluminum Alloy 6063-T6
-
Keyword:
-
Hot Dipped Galvanized Grating
-
Usage:
-
Wall
-
Size:
-
Customized Size
-
Thickness:
-
Custom:3-10mm Routine Use:3mm 4mm 5mm
-
Width:
-
50mm/65mm/70mm/90mm/100mm
-
MOQ:
-
Accept Samples
-
Packing:
-
Standard Sea Worthy Packing
-
Payment term:
-
30%TT Advance + 70% Balance
Product Description
|
Product Name
|
Light steel keel
|
Style
|
Modern
|
|
Brand
|
Shenniao
|
Colour
|
white,Customer's Requirment
|
|
Surface treatment
|
Hot Dipped Galvanized
|
Place of Product
|
Guangxi, China
|
|
Standard
|
ISO9001
|
Modes of packing
|
Carton
|
|
Size
|
Store consultation
Customer's Requirment
|
After sale service
|
Other
|
Types of light steel keel
Light steel joists can be divided into ceiling joists and partition joists according to their purpose, and V-shaped, C-shaped, T-shaped, and L-shaped U-shaped joists according to their cross-sectional form.
The main specifications of the partition keel are Q50, Q75, and Q100
The main specifications of suspended ceiling keel are D38, D45, D50, and D60
Specification
|
Specifications for Middle East
|
|
|
|
Main Channel
|
38*12 38*11 38*10
|
|
|
Furring Channel
|
68*35*22
|
|
|
Wall Angle
|
25*25 24*24 22*22 21*21 30*30
|
|
|
C Stud
|
70*35 73*35 70*32 50*35
|
|
|
U Track
|
72*25 75*25 52*25
|
|
|
Specifications for Auatralia
|
|
|
|
Top Cross Rail
|
26.3*21*0.75
|
|
|
|
25*21*0.75
|
|
|
Furring Channel
|
28*38*0.55
|
|
|
|
16*38*0.55
|
|
|
Furring Channel Track
|
28*20*30*0.55
|
|
|
|
16*26*16*0.55
|
|
|
Stud
|
64*33.5*35.5
|
|
|
|
51*33.5*35.5
|
|
|
|
76*33.5*35.5*0.55
|
|
|
|
92*33.5*35.5*0.55
|
|
|
|
150*33.5*35.5*0.55
|
|
|
Track
|
51*32 64*32 76*32 92*32 150*32
|
|
|
Wall Angle
|
30*10 30*30 35*35
|
|
|
Specifications for Southeast Asia
|
|
|
|
Main Channel
|
38*12
|
|
|
Top Cross Rail
|
25*15
|
|
|
Furring Channel
|
50*19
|
|
|
Cross Channel
|
36*12 38*20
|
|
|
Wall Angle
|
25*25
|
|
|
Stud
|
63*35 76*35
|
|
|
Track
|
64*25 77*25
|
|
|
Spcifications for America
|
|
|
|
Main Channel
|
38*12
|
|
|
Furring Channel
|
35*72*13
|
|
|
Wall Angle
|
25*25 30*30
|
|
|
Stud
|
41*30 63*30 92*30 150*30
|
|
|
Track
|
43*25 63*25 65*25 92*25 152*25
|
|
|
Specifications for Europe
|
|
|
|
CD
|
60*27
|
|
|
UD
|
28*27
|
|
|
CW
|
50*50 75*50 100*50
|
|
|
UW
|
50*40 75*40 100*40
|
|
|
|
|
|
Remark: we can produce the products with
different sizes
as customer requirecustomized.
Packing & Delivery
Packaging & delivery
Packaging Details carton and as customer's request
Packaging Details carton and as customer's request
Port Guangzhou、Shenzhen port
