Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price

Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price

FOB Reference Price: Get Latest Price
≥1 Sets
US $4000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brand Name:
Hengchang
Dimension(L*W*H):
1275x1240mm, 3120*2650*2660 mm, 1150x1275x1240mm, 3120*2650*2660 mm
Weight:
6000 KG
Marketing Type:
New Product 2021
Brand:
Hengchang
The Machines classification:
Mining Machinery
Max feeding size:
250-700 mm
Model:
PF1315 impact stone crusher
Usage:
Mining Crushing
Rotor size:
1000*1050mm
Output size:
1-25mm

Quick Details

Application:
Construction, Construction, Barite, dolomite, kaolin, gypsum
Capacity(t/h):
1150x, 10-200th, Max.10-200th
Place of Origin:
Henan, China
Brand Name:
Hengchang
Dimension(L*W*H):
1275x1240mm, 3120*2650*2660 mm, 1150x1275x1240mm, 3120*2650*2660 mm
Weight:
6000 KG
Marketing Type:
New Product 2021
Brand:
Hengchang
The Machines classification:
Mining Machinery
Max feeding size:
250-700 mm
Model:
PF1315 impact stone crusher
Usage:
Mining Crushing
Rotor size:
1000*1050mm
Output size:
1-25mm
Product Description
Factory Customized Vertical Shaft Impact Crusher Stone Rock Compound Mobile Impact Crusher Primary Machine Price
Combining outstanding manufacturing process and accurate analytic technique, Liming Machine Made Construction Sand Impact Crusher.
Impact Rotary Rock Crusher takes advantages of safety operation and large carrying capacity, particularly, the semi automatic adjusting device highlights intellectualization and advancement.
It is widely used in metallurgy, mine, cement, chemical engineering, fire resistant mterials, ceramics and other industrial sectors, as well as in the expressway construction, water conservancy project, building crushed stone, and machine-made sand process fields, etc.
What is the specifications of the Liming Machine Made Construction Sand Impact Crusher, Impact Rotary Rock Crusher?
Model
Rotor size (mm)
Feed opening (mm)
Max. Feed size (mm)
Capacity (t/h)
Power (kW)
Weight (t)
Overall dimension (mm)
PFW1315Ⅲ
1300×1500
625×1530
300
180-270
200(270)
20
2960×2570×2380
PFW1318Ⅲ
1300×1800
625×1830
300
220-300
250(350)
23
2960×2870×2380
PFW1415Ⅲ
1400×1500
800×1530
350
280-350
250(350)
22.5
3120x2650x266
Model
Rotor size (mm)
Feed opening (mm)
Max. Feed size (mm)
capacity (t/h)
Power (kW)
Weight (t)
Overall dimension (mm)
PFW1315Ⅱ
1300×1500
1200x1530
600
180-320
200(270)
21.5
2700x2570x2800
PFW1318Ⅱ
1300×1800
1200x1830
700
240-400
250(350)
25.5
2700x2870x2800
PFW1415Ⅱ
1400×1500
1300x1530
700
300-480
250(350)
25
2900x2700x3000
Product Feature
Working principle
The machine is a kind of crushing equipment which can use the impact energy to break the material.when the material ehters the plate hammer function area,high-speed impact plate hammer the broken material constantly ran to the impact device above the rotor plate,then bounced back plate hammer area again from the back lining mterial,from big to small in the crushing cavity repeated broken Until the material is broken to the required size,the lower part of the machine is dischanged.
Application
Widely used in mining,sand and gravel,water conservancy and hydropower,highway.railway,chemical industry,building materials and
other industries in the crushing and plastic the machine has a simple structure,no key connection, unique counter lining, high efficiency and energy saving,the product is cubic, the size of the particile size can be adjusted,the crushing process can be simplified,and the production cost can be saved.
Impact crusher features:
1.Wide feeding inlet, high crushing cavity,.
2.Suitable for materials with high hardness and lumpiness, less stone powder and
suitable for requirement of high-quality materials.
3.Complete crushing function, high productivity, less consumption of machine parts and
high comprehensive efficiency.
4.Keyless connection, convenient maintenance, economical and reliable.
