Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
persino
-
Model Number:
-
PSMT96V1000WBL
-
Torque:
-
33N
-
Certification:
-
CE
-
Rated Voltage:
-
72v
-
usage:
-
electric vehicle
-
Color:
-
silver and blue
-
GEAR RATIO:
-
6:1
-
EFFENCIFY:
-
>80%
-
NET WEIGHT:
-
6.2KG
-
CONTROLLER MAX CURRENT:
-
45-50A
-
CONTROLLER UNDER VOLTAGE:
-
52.5V
-
RATED SPEED(+-5%):
-
3200RPM
Quick Details
-
Speed(RPM):
-
3200rpm
-
Continuous Current(A):
-
20A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
persino
-
Model Number:
-
PSMT96V1000WBL
-
Torque:
-
33N
-
Certification:
-
CE
-
Rated Voltage:
-
72v
-
usage:
-
electric vehicle
-
Color:
-
silver and blue
-
GEAR RATIO:
-
6:1
-
EFFENCIFY:
-
>80%
-
NET WEIGHT:
-
6.2KG
-
CONTROLLER MAX CURRENT:
-
45-50A
-
CONTROLLER UNDER VOLTAGE:
-
52.5V
-
RATED SPEED(+-5%):
-
3200RPM
|
350W BLDC MID MOTOR
|
1KW /1.5KW 2.2KW BLDC MID MOTOR
|
|
|
|
||||
|
MODEL
|
PSMT-24350BL
|
PSMT-36350BL
|
PSMT-48350BL
|
PSMT-60350BL
|
||||
|
SPEC.
|
24V350W
|
36V350W
|
48V350W
|
60V350W
|
||||
|
RATED VOLTAGE
|
24V
|
36V
|
48V
|
60V
|
||||
|
RATED POWER
|
350W
|
350W
|
350W
|
350W
|
||||
|
RATED SPEED(+-5%)
|
2300RPM
|
2500RPM
|
2700RPM
|
2800RPM
|
||||
|
RATED TORQUE
|
11N
|
8.5N
|
11N
|
11N
|
||||
|
RATED CURRENT
|
18A
|
16A
|
9A
|
7A
|
||||
|
GEAR RATIO
|
6:1
|
6:1
|
6:1
|
6:1
|
||||
|
EFFENCIFY
|
＞80%
|
＞80%
|
＞80%
|
＞80%
|
||||
|
NET WEIGHT
|
4.4KG
|
4.4KG
|
4.4KG
|
4.4KG
|
||||
|
CONTROLLER MAX
CURRENT |
20-22A
|
22A
|
22-25A
|
22-25A
|
||||
|
CONTROLLER UNDER VOLTAGE
|
20.5V
|
31.5V
|
42V
|
52.5V
|
||||
|
500W BLDC MID MOTOR
|
1KW /1.5KW 2.2KW BLDC MID MOTOR
|
|
|
|
||||
|
MODEL
|
PSMT-24500BL
|
PSMT-36500BL
|
PSMT-48500BL
|
PSMT-60500BL
|
||||
|
SPEC.
|
24V500W
|
36V500W
|
48V500W
|
60V500W
|
||||
|
RATED VOLTAGE
|
24V
|
36V
|
48V
|
60V
|
||||
|
RATED POWER
|
500W
|
500W
|
500W
|
500W
|
||||
|
RATED SPEED(+-5%)
|
2200RPM
|
2400RPM
|
2700RPM
|
2800RPM
|
||||
|
RATED TORQUE
|
16N
|
12N
|
16N
|
17N
|
||||
|
RATED CURRENT
|
24A
|
21A
|
13A
|
10A
|
||||
|
GEAR RATIO
|
6:1
|
6:1
|
6:1
|
6:1
|
||||
|
EFFENCIFY
|
＞80%
|
＞80%
|
＞80%
|
＞80%
|
||||
|
NET WEIGHT
|
4.5KG
|
4.5KG
|
4.5KG
|
4.5KG
|
||||
|
CONTROLLER MAX
CURRENT |
28-30A
|
28-30A
|
30A
|
30-33A
|
||||
|
CONTROLLER UNDER VOLTAGE
|
20.5V
|
31.5V
|
42V
|
52.5V
|
||||
|
750W BLDC MID MOTOR
|
1KW /1.5KW 2.2KW BLDC MID MOTOR
|
|
|
|
||||
|
MODEL
|
PSMT-36750BL
|
PSMT-48750BL
|
PSMT-60750BL
|
PSMT-72750BL
|
||||
|
SPEC.
|
36V750W
|
48V750W
|
60V750W
|
72V750W
|
||||
|
RATED VOLTAGE
|
36
|
48V
|
60V
|
72V
|
||||
|
RATED POWER
|
750W
|
750W
|
750W
|
750W
|
||||
|
RATED SPEED(+-5%)
|
2600RPM
|
2700RPM
|
2800RPM
|
2900RPM
|
||||
|
RATED TORQUE
|
17N
|
17N
|
17N
|
17N
|
||||
|
RATED CURRENT
|
25A
|
19A
|
15A
|
13A
|
||||
|
GEAR RATIO
|
6:1
|
6:1
|
6:1
|
6:1
|
||||
|
EFFENCIFY
|
＞80%
|
＞80%
|
＞80%
|
＞80%
|
||||
|
NET WEIGHT
|
5.6KG
|
5.6KG
|
5.6KG
|
5.6KG
|
||||
|
CONTROLLER MAX
CURRENT |
35-40A
|
35-40A
|
35-40A
|
35-40A
|
||||
|
CONTROLLER UNDER VOLTAGE
|
31.5V
|
42V
|
52.5V
|
63V
|
||||
|
800W BLDC MID MOTOR
|
1KW /1.5KW 2.2KW BLDC MID MOTOR
|
|
|
|
||||
|
MODEL
|
PSMT-36800BL
|
PSMT-48800BL
|
PSMT-60800BL
|
PSMT-72800BL
|
||||
|
SPEC.
|
36V800W
|
48V800W
|
60V800W
|
72V800W
|
||||
|
RATED VOLTAGE
|
36
|
48V
|
60V
|
72V
|
||||
|
RATED POWER
|
800W
|
800W
|
800W
|
800W
|
||||
|
RATED SPEED(+-5%)
|
2600RPM
|
2700RPM
|
2800RPM
|
2900RPM
|
||||
|
RATED TORQUE
|
29N
|
27N
|
26N
|
25N
|
||||
|
RATED CURRENT
|
27A
|
20A
|
16A
|
14A
|
||||
|
GEAR RATIO
|
6:1
|
6:1
|
6:1
|
6:1
|
||||
|
EFFENCIFY
|
＞80%
|
＞80%
|
＞80%
|
＞80%
|
||||
|
NET WEIGHT
|
5.6KG
|
5.6KG
|
5.6KG
|
5.6KG
|
||||
|
CONTROLLER MAX
CURRENT |
38-42A
|
38-42A
|
38-42A
|
38-42A
|
||||
|
CONTROLLER UNDER VOLTAGE
|
31.5V
|
42V
|
52.5V
|
63V
|
||||
|
1KW BLDC MID MOTOR
|
1KW /1.5KW 2.2KW BLDC MID MOTOR
|
|
|
|
||||
|
MODEL
|
PSMT-361000BL
|
PSMT-481000BL
|
PSMT-601000BL
|
PSMT-721000BL
|
||||
|
SPEC.
|
36V1000W
|
48V1000W
|
60V1000W
|
72V1000W
|
||||
|
RATED VOLTAGE
|
36V
|
48V
|
60V
|
72V
|
||||
|
RATED POWER
|
1000W
|
1000W
|
1000W
|
1000W
|
||||
|
RATED SPEED(+-5%)
|
3000RPM
|
3200RPM
|
3200RPM
|
3200RPM
|
||||
|
RATED TORQUE
|
35N
|
34N
|
31N
|
29N
|
||||
|
RATED CURRENT
|
34A
|
25A
|
20A
|
17A
|
||||
|
GEAR RATIO
|
6:1
|
6:1
|
6:1
|
6:1
|
||||
|
EFFENCIFY
|
＞80%
|
＞80%
|
＞80%
|
＞80%
|
||||
|
NET WEIGHT
|
6.2KG
|
6.2KG
|
6.2KG
|
6.2KG
|
||||
|
CONTROLLER MAX
CURRENT |
45-50A
|
45-50A
|
45-55A
|
45-55A
|
||||
|
CONTROLLER UNDER VOLTAGE
|
31.5V
|
42V
|
52.5V
|
63V
|
||||
