Custom Laser Etched Rocker Switch Boat On Off Marine Rocker Switch 12V 20A Waterproof Lamp Rocker Switch for Truck Panel Mount

Custom Laser Etched Rocker Switch Boat On Off Marine Rocker Switch 12V 20A Waterproof Lamp Rocker Switch for Truck Panel Mount

FOB Reference Price: Get Latest Price

≥10 Pieces

US $1.9

≥100 Pieces

US $1.77

≥300 Pieces

US $1.64

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: DR-AxxJ

Max. Current:: 20A

Mechanical Life:: 100000 Cycles

Products name:: Marine Switch

Rating:: 20A 12VDC/ 10A 24VDC

Protect Level:: IP66 Waterproof

Base:: 8pins, 6pins, 8pins/barriers, 10pins

Pole:: Single Pole, Double Poles

Light:: 2-Lights

Terminal Number:: 2pins-8pins

Function 1:: ON-OFF,(ON)-OFF,ON-ON,(ON)-ON,ON-OFF-ON,(ON)-OFF-ON

Function 2:: (ON)-OFF-(ON),ON-ON-ON,ON-ON-OFF,(ON)-ON-OFF,(ON)-ON-ON

Light Colors:: Red, Green, Blue, Orange, White

Quick Details

Max. Voltage:: 24V DC

Place of Origin:: Zhejiang, China

Brand Name:: Daier

Model Number:: DR-AxxJ

Max. Current:: 20A

Mechanical Life:: 100000 Cycles

Products name:: Marine Switch

Rating:: 20A 12VDC/ 10A 24VDC

Protect Level:: IP66 Waterproof

Base:: 8pins, 6pins, 8pins/barriers, 10pins

Pole:: Single Pole, Double Poles

Light:: 2-Lights

Terminal Number:: 2pins-8pins

Function 1:: ON-OFF,(ON)-OFF,ON-ON,(ON)-ON,ON-OFF-ON,(ON)-OFF-ON

Function 2:: (ON)-OFF-(ON),ON-ON-ON,ON-ON-OFF,(ON)-ON-OFF,(ON)-ON-ON

Light Colors:: Red, Green, Blue, Orange, White

* 【Custom Appearance and Function 】 - Both the function and pattern of this switch can be customized. You can choose the function you need, and we can also laser engrave any pattern you want for you!
* 【Easy to Install】 - Mounting hole size of the bilge pump switch is 1.46" (37.2 mm) x 0.83" (21.2 mm), suit for most vehicles boat install or replace. It controls any pump equipped with an automatic float switch.
* 【High Quality】 - The 20A Marine Rocker Switch is made of strengthened ABS and anti-retardant materials, which makes it more waterproof, shockproof and durable.
* 【Wide Application】 - Universal for all cars, RVs, SUV, ATV, UTV, Cans, Motorcycles, buses, marine boats, yachts, trailers,
jeeps, prerunners, camper, caravans, engineering vehicles, special vehicle etc.

Products Description

Product Name	DR-AxxJ Marine Switch
Rating	204 12VDC/104 24VDC
Protect Level	IP66 Waterproof
Base	8pins, 6pins,8pins/barriers, 10pins
Pole	Single Pole, Double Poles
Light	2-Lights
Light Colors	Red, Green, Blue, Orange, White
Terminal Number	2pins-8pins
Function 1	ON-OFF,(ON)-OFF,ON-ON,(ON)-ON,ON-OFF-ON,(ON)-OFF-ON
Function 2	(ON)-OFF-(ON),ON-ON-ON,ON-ON-OFF,(ON)-ON-OFF,(ON)-ON-ON

—— Products Details ——

DR-AxxJ Marine Rocker Switch

Function Choose:

ON-OFF

(ON)-OFF

ON-ON

(ON)-ON

ON-OFF-ON

(ON)-OFF-ON

(ON)-OFF-(ON)

ON-ON-ON

ON-ON-OFF

(ON)-ON-OFF

(ON)-ON-ON

Other Products

Workshop

Product Certified

Exhibition

Our team

FAQ

1.Q: Could I put my own logo on the products?

A: Sure, your logo can be put on every product, either by laser, or by moulds.

2.Q: Could I put my own designs of label on the products?
A: Of course, you can send us your design, we'll follow your design.

3.Q: Can I have some samples before formal order?
A: Yes. we can send you some free samples for your test before your order.

4.Q: How long is the lead time?
A: Normally we keep stock for most products, the lead time is 1-5 days as soon as the payment is released.
For customized products, it takes longer.

5.Q: How about the after-sale service? What's the Warranty terms?
A: We offer 12 months for every products we sold. If you meet any problems after sales, pis contact us freely,
we'll help solving the problems within 24 hours.

6.Q: Are you manufacturer or just dealer?
A: We're manufaturer, we do produce all products by ourself. Welcome to visit our plant at any time.

7.Q: What's the payment terms? Can I pay after you got the products?
A: Normally we accept TT and western union. L/C is also accepted if the order quantity is large. For old customers,
we'll guanartee monthly payment after good cooperationship.

8.Q: I couldn't find the products I want in your catalogue, can you develop it for me?
A: Yes. we have a research & development dept.
