Quick Details
-
Place of Origin:
-
Hebei, China
Quick Details
-
Material:
-
Galvanized Iron Wire
-
Type:
-
Welded Mesh
-
Application:
-
Construction Wire Mesh
-
Place of Origin:
-
Hebei, China
The mesh is made of high corrosion resistance, high strength and ductility of low carbon steel wire or over steel wire coated with PVC.According to ASTM and EN standards, the diameter of mild steel wire used varies according to engineering design requirements.Generally between 2.0mm and 4.0mm, the tensile strength of stone cage wire shall be no less than 38kg/m2, the weight of metal coating shall be generally higher than 245g/m2, and the diameter of edge line of stone cage wire shall be generally greater than that of wire line.The length of the stranded part of double wire shall not be less than 50mm. In order to ensure that the metal plating layer and PVC plating layer of the twisted part will not be damaged.
Parameter
(1) aperture: 60*80mm, 80*100mm, 80*120mm, 100*120mm, 120*150mm, 90*110mm
The length of the twisted part of double wire shall not be less than 50mm. In order to ensure that the steel and PVC plating of the twisted part will not be damaged.
(2) wire diameter: there are three kinds of wire diameter - wire, edge and binding
1. The range of the wire is 2mm-4mm
2. The side wire is generally larger than the net wire and is 0.5-1.0mm thicker than the net wire
3. The binding wire is generally smaller than the net wire, and the most common one is 2.2mm
(3) wire tension: not less than 38kg/m2 380N/mm
(4) surface treatment
1. Galvanizing.The maximum amount of upper zinc is 10g/m2.Anticorrosion sex difference
2. Hot galvanizing.The maximum amount of zinc can reach 300g/m2.Strong corrosion resistance
3. Galfan (zinc-aluminium alloy).This is divided into two materials: zn-5% al-mixed rare earth alloy steel wire and zn-10% al-mixed rare earth alloy steel wire.Ultra strong corrosion resistance
4. PVC plastic coated.The thickness of plastic bags is generally 1.0mm, for example: 2.7mm after wrapping is 3.7mm.Anticorrosion strong
(1) partition: one partition is added per meter in the long direction of the stone cage net
(2) size: customized according to the standard
(3) the range of aperture and silk diameter
The stone cage net is made of hexagonal twisting and weaving: raw material selection (wire rod) -- cold drawing/galvanizing/plastic-wrapping -- machine knitting -- artificial shear, assembly -- product inspection -- packaging and transportation
