Quick Details
-
Weight:
-
2250 KG, 2000kg
-
Product name:
-
Crawler Tractor
-
Model:
-
GT702
-
MOQ:
-
1 Set
-
Package:
-
3 machines in a 40'HQ container
-
Size Length * Width * Height (mm):
-
3327 * 1450 * 2400
-
Engine Type:
-
Diesel, water cooled, four stroke, Electrical start
-
Engine Rated power:
-
51.5kw / 2400rpm
-
Steering system:
-
Planetary differential steering
-
Braking system:
-
Wet friction braking
Quick Details
-
Rated Power (HP):
-
51.5 / 2400rpm
-
Brand Name:
-
Gookma
-
Place of Origin:
-
Guangxi, China
-
Weight:
-
2250 KG, 2000kg
-
Product name:
-
Crawler Tractor
-
Model:
-
GT702
-
MOQ:
-
1 Set
-
Package:
-
3 machines in a 40'HQ container
-
Size Length * Width * Height (mm):
-
3327 * 1450 * 2400
-
Engine Type:
-
Diesel, water cooled, four stroke, Electrical start
-
Engine Rated power:
-
51.5kw / 2400rpm
-
Steering system:
-
Planetary differential steering
-
Braking system:
-
Wet friction braking
Products Description
|
Specifications
|
|
|
|
|
||||
|
Name
|
|
Crawler Tractor
|
|
|
||||
|
Model
|
|
GT702
|
|
|
||||
|
Dimensions
|
Length*Width*Height (mm) (in)
|
|
3690*1500*2400 (145*59*95)
|
|
||||
|
Weight
|
kg (lb)
|
|
2250 (4960)
|
|
||||
|
Ground clearance
|
mm (in)
|
|
440 (17)
|
|
||||
|
Engine
|
Type
|
|
Diesel, water cooled, four stroke, Electrical start
|
|
||||
|
|
|
|
|
|
||||
|
|
Rated power (kw)
|
|
51.5 / 2400rpm
|
|
||||
|
Steering system
|
|
|
Planetary differential steering
|
|
||||
|
Braking system
|
|
|
Wet friction braking
|
|
||||
|
Transmission system
|
Clutch type
|
|
Monolithic single-acting
|
|
||||
|
|
Gear box type
|
|
8 forward speed + 8 reverse speed
|
|
||||
|
|
|
|
|
|
||||
|
|
Gear box shifting mode
|
|
Manual
|
|
||||
|
Walking system
|
Rack form
|
|
Rigid frame
|
|
||||
|
|
Track number*pitch*width (mm) (in)
|
|
51*90*350 (51*3.55*13.8)
|
|
||||
|
|
Designed speed (km/h )(ft/h)
|
forward / backward
|
Low
|
High
|
||||
|
|
|
First gear
|
1.22 (48)
|
5.5 (217)
|
||||
|
|
|
Second gear
|
1.8 (71))
|
8.08 (318)
|
||||
|
|
|
Third gear
|
2.92 (115）
|
13.13 (517)
|
||||
|
|
|
Forth gear
|
3.84 (151)
|
17.25 (680)
|
||||
|
Working Device
|
Tillage depth control mode
|
|
Force position control
|
|
||||
|
|
Power output shaft form
|
|
Detached
|
|
||||
|
|
Power output shaft speed (rpm)
|
|
720
|
|
||||
|
|
PTO shaft spline diameter (mm) (in)
|
|
8*38 (8*1.50)
|
|
||||
|
|
|
|
|
|
||||
Features and Advantages:
1.The GT702 crawler tractor adopts double power flow fluid control differential steering system, it can make pivot steering for 360 degree.
2.Adopts mechanical transmission, high transmission efficiency, low fuel consumption, specially suitable for rotary cultivation and plain working in big field.
3.Steering wheel control, it’s accurate, comfortable and flexible.
4.Small grounding pressure, high ground clearance, good passing ability, realizes a protection cultivation.
5.Compact structure, low barycentre, good safety performance.
6.It’s convenient in operating, it may be operated by both male and female easily. It’s small size, light weight, easy in travel control, flexible in turning. It’s simple in disassembling and convenient for maintenance.
7.The tractor is of multifunctional, different job can be made by replacing the working devices, such as bulldozing, ploughing, leveling, ridging, ditching, planting, earthing, holing, fertilizing, transporting, water pumping, loading, digging, spraying etc.
