Quick Details
-
Brand Name:
-
songbai
-
Voltage:
-
380V
-
Weight (KG):
-
500 KG
-
Marketing Type:
-
New Product 2021
-
Application:
-
Making Wood Pellets
-
Name:
-
wooden pallet production line
-
Product name:
-
rice husk pellet making machine
-
Raw material:
-
Pine Sawdust straw rice Husk wood Waste
-
Usage:
-
Sawdust Fuel Pellet Making Machine
-
Keywords:
-
wood pellet making machine
-
Package:
-
Wooden Case
-
Pellet size:
-
6/8/10/12mm
-
Color:
-
Customer's Request
-
Advantage:
-
High Performance
Quick Details
-
Pellet Diameter (mm):
-
6 - 12
-
Output (kg/h):
-
100 - 1000 kg/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
songbai
-
Voltage:
-
380V
-
Weight (KG):
-
500 KG
-
Marketing Type:
-
New Product 2021
-
Application:
-
Making Wood Pellets
-
Name:
-
wooden pallet production line
-
Product name:
-
rice husk pellet making machine
-
Raw material:
-
Pine Sawdust straw rice Husk wood Waste
-
Usage:
-
Sawdust Fuel Pellet Making Machine
-
Keywords:
-
wood pellet making machine
-
Package:
-
Wooden Case
-
Pellet size:
-
6/8/10/12mm
-
Color:
-
Customer's Request
-
Advantage:
-
High Performance
Product Description
Wooden Pallet Production Line
Overview
|
*
Production Line Name
: New Type Wood Pallets Pellets Mill Machine Biomass Wood Pellet Production Line With Pellet Machine
|
|
|
|
|
||||
|
*
Capacity Of This Line
: 1-20 T/H
|
|
|
|
|
||||
|
*
Function Description
: Making Wood Pellets, Biomass Pellets.
|
|
|
|
|
||||
|
*
Type Of Raw Material
: Wood Logs, Sawdust, Planks, Straws, Other Biomass Wastes Etc.
|
|
|
|
|
||||
|
*
Final Pellet Size
: 6/8/10/12mm Or Other Customized Sizes.
|
|
|
|
|
||||
|
*
Main Machines Used
: Wood Pellet Machine, Drum Type Wood Chipper, Hammer Mill, Rotary Drum Type Drying Machine, Counterflow Cooler,Automatic Packing System.
|
|
|
|
|
||||
Advantages of Biomass Wood Pellet Machine Line
|
1).
Ring Die Type Pellet Mill
:The high-efficiency ring die type pellet machine can produce high-quality pellets with high compression ratio and high calorific value.
|
|
|
|
|
||||
|
2).
Long Service Life
: Each machine is tested before shipment to ensure that it runs without fault.
|
|
|
|
|
||||
|
3).
Unique Design
: Adopting exclusive design to make the entire production line efficient and energy-saving. Contact us for more details about our design.
|
|
|
|
|
||||
|
4).
Customizable
: Customized design solutions can handle materials of various sizes and types of raw materials. Meet the different needs of customers in different markets.
|
|
|
|
|
||||
|
5).
After-sales Service
: More than 30 years of production experience, providing installation, training, and continuous after-sales service.
|
|
|
|
|
||||
Wood Production Line Process
|
Crushing Section
|
|
Name
:Hammer Mill/Crusher
|
|
Usage
: Crush the wood chips/wood shaving/small blocks/grass/stalk...to 6-8mm powder.
|
|
Finished products
: 6-8mm(depends on the size of screener hole.)
|
|
Drying Section
|
|
Name
: Rotary Dryer
|
|
Usage
: dry raw material into suitable moisture to produce high-level pellets.
|
|
Finished moisture
: 10-15%
|
|
Pelletizing Section
|
|
Name
: Wood Pellet Machine
|
|
Usage
: press crushed and dry sawdust/rice husk/straw/grass... into pellets.
|
|
Finished pellets
: 6/8/10mm.(Asian Market standard: 8mm; European Market standard: 6mm)
|
|
Cooling Section
|
|
Name
: Cooling Machine
|
|
Usage
: cool high-temperature pellets before packing.
|
|
Reason:
the finished pellets are very hot and realease moisture as they leave the pellet machine. This section can ensure to generate smooth pellets.
|
|
Packing Section
|
|
Name
: Packing Machine
|
|
Usage
: Pack pellets into 20-50kg/bag or 1 ton bag.
|
|
Advantage
: easily to be transported to final users' site.
|
Specification
Different Capacity Biomass Wood Pellets Machine Line Specifications
According the the different capacity, we have many models for the wood pellet mill line, you can check the below specification to check which model you prefer to , if you have any interest, you can contact us freely, we glad to provide more professional recommend to you.
|
Can Customize The Biomass Wood Pellet Production Line For You
|
Capacity (kg/h)
|
Power
(kw)
|
Pellet Diameter
(mm) |
Weight
(kg)
|
Machine Size
(mm)
|
|||||
|
Name
|
Capacity Range
|
Area Requirement
|
Final Product Pellet Size
|
Pellet Integrity
|
Automatic Control
|
|||||
|
Wood Pellet Production Line
|
1-120 T/H
|
18 square meter
(For Minimum Capacity) |
6/8/10/12 MM And Other Customized Size
|
About 99%
|
Support
|
|||||
Wood Pellet Machine Line
Customer Case
Product Show
Product Application
The size of the sawdust wood pellets we produce is 6mm 8mm 10mm,b
iomass pellets are made by recycling waste and are a new type of environmentally friendly fuel, widely used in residential heating equipment, power plants, boiler plants, etc. It has the characteristics of large heat generation, low ash content, low environmental pollution, and recyclability.
Packing & Delivery
Wood pellet making machine packing and shipping
Packed in standard wooden case
Shipping by sea
