Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZGSM
-
Application:
-
,construction,gas containers, etc
-
Product Name:
-
Spring steel strip
-
thickness:
-
0.12-2.6mm,customized
-
Hardess:
-
43-49HRC
-
Technique:
-
Cold Rolled, HOT Rolled Finish
-
color:
-
Primary, white, blue, black, green, coffee , grey
-
Heat treatment mode:
-
Annealing,Cold hard,Annealing
-
tempering:
-
760-780℃,etc
Quick Details
-
Grade:
-
65Mn/50#/C75S/70Mn
-
Tolerance:
-
±1%
-
Dimensions:
-
30-300mm (Width tolerance:±0.2mm)
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZGSM
-
Application:
-
,construction,gas containers, etc
-
Product Name:
-
Spring steel strip
-
thickness:
-
0.12-2.6mm,customized
-
Hardess:
-
43-49HRC
-
Technique:
-
Cold Rolled, HOT Rolled Finish
-
color:
-
Primary, white, blue, black, green, coffee , grey
-
Heat treatment mode:
-
Annealing,Cold hard,Annealing
-
tempering:
-
760-780℃,etc
65mn roller shutter door spring 65mn cold hot rolled high carbon spring steel strip For Construction Product
Products Description
Spring steel strip coil
Heat treatment： Quench 830 °C ± 20 °C, oil cooling; tempering 540 °C ± 50 °C
Mechanical properties： Tensile strength σb (MPa): ≥ 980 (100),Yield strength σs(MPa): ≥784(80), Elongation δ10(10%):≥8,Section shrinkage ψ(%):≥30,Hardness: Hot Rolling, ≤302HB;Cold Pull+Heat Treatment,≤321HB.
Packing： Export standard packing or according to customers’ requirement
Shipment：Within10-15 workdays,25-30days when the quantity beyond 1000tons
Heat treatment： Quench 830 °C ± 20 °C, oil cooling; tempering 540 °C ± 50 °C
Mechanical properties： Tensile strength σb (MPa): ≥ 980 (100),Yield strength σs(MPa): ≥784(80), Elongation δ10(10%):≥8,Section shrinkage ψ(%):≥30,Hardness: Hot Rolling, ≤302HB;Cold Pull+Heat Treatment,≤321HB.
Packing： Export standard packing or according to customers’ requirement
Shipment：Within10-15 workdays,25-30days when the quantity beyond 1000tons
appliations: for the production of roller shutter springs
material: C67S, C75S, C80S (SAE1070,SAE1075, SAE1080)
surface: polished blue/grey
edge: rounded
hardness: 44-48hrc
material: C67S, C75S, C80S (SAE1070,SAE1075, SAE1080)
surface: polished blue/grey
edge: rounded
hardness: 44-48hrc
|
Product Name
|
Spring steel strip
|
|
Standard
|
AISI, ASTM, BS, DIN, GB, JIS,etc
|
|
Material
|
65Mn/50#/C75S/70Mn/En1.8159/SUP10/6150/EN1.7102/SK75 /CK67/51CRV4 /C80,etc
|
|
Supplier
|
HBIS, AnSteel(Sochi Olympic Supplier), BaoSteel, etc
|
|
Thickness
|
0.12-2.6mm,customized
|
|
Width
|
80-1500mm,customized
|
|
Hardess
|
43-49HRC
|
|
Heat treatment mode
|
Annealing,Cold hard,Annealing or high temperature tempering,760-780℃,etc
|
Product Show
1.Primary color steel strap is also called the white packing steel strap, and the white color is the bright primary colors after
cold rolling. They needn't do any other surface treatment, only need coat a layer of anti-rust oil. This kind of packaging with
low price, some foreign countries used them as building material and in general their dosage is very large. Commonly, it adopts 3-4 layer packaging, or packaging according to customer requirements.
cold rolling. They needn't do any other surface treatment, only need coat a layer of anti-rust oil. This kind of packaging with
low price, some foreign countries used them as building material and in general their dosage is very large. Commonly, it adopts 3-4 layer packaging, or packaging according to customer requirements.
1. Bluing steel strapping is to heat treatment the steels at about 200 degree centigrade and make the steel surface to form a yer of dense ferroferric oxide film. Its main ingredient is ferroferric oxide
2. Paint steel belt is a new type used for strapping cargo packing belt, it has better performance in all aspects than other common steel belts. Firstly, embodied in the painted steel belt won't appear rusty phenomenon, it does not like ordinary steel belt packaging rusty spot goods, more environmental protection. Secondly, painted steel belt after cold rolling, shearing, bluing or paint or galvanized, and so on, the finished good elongation, tensile strength, the goods strapping compared strong trust, this is also why painted steel belt is more and more popular.
3.Galvanized packing steel straps adopt ordinary carbon structural steel or high quality carbon structural steel, through cold
rolled, electric blue and galvanized. Galvanized steel strip is bluing further deep processing of steel belt, this product is on
the basis of bluing steel straps to do the galvanized processing, solved the problem of the steel strip rust. It is Suitable for
the packing of wood, paper, glass, stone, steel strapping packing, welded pipe and other large objects.
rolled, electric blue and galvanized. Galvanized steel strip is bluing further deep processing of steel belt, this product is on
the basis of bluing steel straps to do the galvanized processing, solved the problem of the steel strip rust. It is Suitable for
the packing of wood, paper, glass, stone, steel strapping packing, welded pipe and other large objects.
|
product name
|
|
metrial
|
brand
|
|
|
coil weight (kg)
|
APPLICATION
|
||
|
|
|
|
|
thickness
|
wide
|
|
|
||
|
Cold rolled carbon structural steel
|
|
carbon steel strip
|
GB716-1991
|
0.2-2.5
|
10-17
|
0.19-760
|
Civil hardware, light industry, steel and wood furniture
|
||
|
Blue steel tape galvanized steel tape for packaging
|
carbon steel
|
GB4173-84
|
0.3-1.65
|
8-51
|
15-92
|
Nonferrous metals, textile, paper, steel
|
|
Composite cold rolled steel strip for rubber
|
O8AI
|
QJ/AD2.19-89
|
0.5
|
16-50
|
28-90
|
Automobile sealing tape
|
|
Low carbon steel cold rolled strip
|
low carbon steel
|
GB3463-83
|
0.2-2.5
|
20-170
|
34-760
|
Deep drawing products, electrical instruments
|
|
The chain is cold-rolled steel strip
|
20MnSi40Mn
|
GB3463-83
|
1.2-2.0
|
60-160
|
110-710
|
Executive car, motorcycle, industrial chain
|
|
Cold rolled steel strip for welding tube
|
Q195Q215
|
GB8164-87
|
0.5-2.0
|
50-170
|
90-760
|
Steel window, steel and wood furniture, transformer
|
|
Cold rolled steel strip for radiator
|
08AI
|
GB3526-83
|
0.3-1.2
|
10-170
|
18-760
|
Radiators, chillers, hoses
|
|
Corrugated tube steel strip
|
Q195Q215
|
GB4175.1-84
|
0.2-0.8
|
35-100
|
62-450
|
Bridge, long span building beam
|
|
Galvanized steel tape for armored cables
|
Q215
|
GB4175.2-84
|
0.2-1.0
|
10-60
|
18-110
|
Cable sheath
|
|
Painted steel tape for armored cables
|
Q215
|
GB4175.1-84
|
0.2-1.0
|
10-60
|
18-110
|
Cable sheath
|
|
Bright annealed steel strip
|
carbon steel
|
GB716-83
|
0.4-0.2
|
10-300
|
19-1500
|
Duct tape, prickle tape
|
Pickling--normal temperature rolling -- process lubrication -- annealing -- leveling -- fine cutting -- packaging
