- Product Details
- {{item.text}}
Quick Details
-
Type:
-
Pure Sine Wave Inverter
-
Rated power:
-
4000W-6000W
-
Display:
-
Digital LCD
-
Certificate:
-
CE
-
Frequency:
-
50Hz/60Hz
-
Application:
-
Home Appliance
-
Protection:
-
Overload and short circuit
-
Output waveform:
-
Pure Sine Wave Output
-
Efficiency:
-
91%
-
Warranty:
-
1 Year
Quick Details
-
Place of Origin:
-
shenzhen china
-
Model Number:
-
RP SERIES
-
Brand Name:
-
SUMRY
-
Type:
-
Pure Sine Wave Inverter
-
Rated power:
-
4000W-6000W
-
Display:
-
Digital LCD
-
Certificate:
-
CE
-
Frequency:
-
50Hz/60Hz
-
Application:
-
Home Appliance
-
Protection:
-
Overload and short circuit
-
Output waveform:
-
Pure Sine Wave Output
-
Efficiency:
-
91%
-
Warranty:
-
1 Year
Pure sine wave inverter
Output power factor 1
Selectable high power charging current
Selectable input voltage range for home appliances and personal computers
Configurable AC/battery input priority via LCD setting
Compatibe with generator power
Auto restart while AC is recovering
Overload and short circuit protection
Smart battery charger design for optimized battery performance
Cold start function
Color LCD display
Support the use lithium batteries
|
MODEL |
RP 4000 |
RP 5000 |
RP 6000 |
|
Rated Power |
4000W |
5000W |
6000W |
|
INPUT |
|||
|
Voltage |
100/110120Vac;220/230/240Vac |
||
|
Selectable Voltage Range |
Wide Range:75Vac-138Vac; 170-280VAC(for personal computers) Narrow Range:82Vac-138Vac; 90-280VAC(for home appliances) |
||
|
Frequency Range |
40-70Hz(50Hz/60Hz) |
||
|
OUTPUT |
|||
|
AC Voltage Regulation (Batt.Mode) |
100/110/120Vac(±5V);220/230/240Vac(±10V) |
||
|
Surge power |
12000VA |
15000VA |
18000VA |
|
Efficiency(Peak) |
91% |
||
|
Transfer Time |
<10ms |
||
|
Wave form |
Pure Sine Wave |
||
|
BATTERY & AC CHARGER |
|||
|
Battery Voltage |
24V/48V |
24V/48V |
24V/48V |
|
Charge Current |
75A/35A |
75A/45A |
75A/50A |
|
Fast Charge Voltage |
14.3VDC for 12V(*2 for 24V,*4 for 48V) |
||
|
Floating Charge Voltage |
1 3.7 VDC for 12V(*2 for 24V,*4 for 48V)
|
||
|
Battery Low Voltage Alarm |
16.5VDC for 12V(*2 for 24V,*4 for 48V)
|
||
|
Over Voltage Protect |
10.5 VDC for 12V(*2 for 24V,*4 for 48V) |
||
|
Battery Low Voltage Shutdown |
10.0 VDC for 12V(*2 for 24V,*4 for 48V) |
||
|
Protection |
Over charging,over temp,over battery voltage,over load,short-circuit
|
||
|
Operating Enviroment Temperature |
55°C
|
||
|
Cooling |
Intelligent Fan |
||
|
Display |
LCD |
||
|
Specification Setting |
By LCD or position machine Charging current ,battery type,input voltage,output frequency,wide and narrow of AC input voltage,power-saver model,AC priority or battery priorty |
||
|
PHYSICAL |
|||
|
Dimension.D*W*H(mm) |
607*345*198mm |
||
|
Net Weight (kgs) |
34.4/33.8kg |
37.9/38.2kg |
41.6/40.5 |
|
OPERATING ENVIRONMENT |
|||
|
Humidity |
5% to 95% Relative Humidity(No-condensing) |
||
|
Operating Temperature |
-10 ℃ to 50 ℃ |
||
|
Storage Temperature |
-10 ℃ to 60 ℃ |
||
Q1: Why you should choose us?
---More than 20 years Electrical Equipment factory experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 1years warranty and 2% sapre parts for free
---We will repair the PCB or provide new one
Q3: What kind of certification you have?
---ISO9001,ISO14001, CE,ROHS,UL,and so on
---All series product pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days;
Q5. Can I have a sample order?
---Yes, we welcome sample order to test and check quality.
Q6. Do you have any MOQ?
---Yes, we have MOQ for mass production, it depends on the different part numbers. 1~30pcs sample order is available. Low MOQ,1 pc
for sample checking is available.
Q7. Do you support OEM?
---Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
