Quick Details
-
Brand Name:
-
TIBOX
-
Model Number:
-
TP; TPX; ALP
-
External Size:
-
optional
-
Color:
-
RAL 7032 or RAL 7035
-
Material:
-
cold steel sheet & stainless steel
-
Thickness of sheet steel:
-
1.5mm/foot door :2.0mm/upper cover
-
Supply include:
-
control desk , front door with locking system
-
protection degree:
-
IP55
-
certifications:
-
CE IP55 ROHS
-
OEM Ability:
-
Provide OEM
-
Against Mechanical impacts:
-
IK10
-
Breaking capacity:
-
100KA
Quick Details
-
Protection Level:
-
IP55
-
Type:
-
Control Box
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TIBOX
-
Model Number:
-
TP; TPX; ALP
-
External Size:
-
optional
-
Color:
-
RAL 7032 or RAL 7035
-
Material:
-
cold steel sheet & stainless steel
-
Thickness of sheet steel:
-
1.5mm/foot door :2.0mm/upper cover
-
Supply include:
-
control desk , front door with locking system
-
protection degree:
-
IP55
-
certifications:
-
CE IP55 ROHS
-
OEM Ability:
-
Provide OEM
-
Against Mechanical impacts:
-
IK10
-
Breaking capacity:
-
100KA
Waterproof industrial operator control desk distribution panel board
TP /
ALP / AM series control desk
Enclosure & door: 2.0mm sheet steel, galvanised mounting plate: 2.5mm
Color: RAL7032 or RAL7035
Finish: Epoxy polyester powder coating textured finish
Protection degree: IP55
Front / rear door and operation panel can be opened for convent installation.
Zinc coated mounting plate can move back and forth.
ALP series control desk ( include PE, LE, AE )
Supply include: Part PE, part LE, part AE
PE part: Door with lock+hinges, mounting plate, enclosure body
AE part: Door with lock+hinges, mounting plate, enclosure body
LE part: Door with lock+hinges, door support 2pcs/set, enclosure body
Supply include -control desk;
-front door with lock system;
-upper cover with cover stop 2pcs;
-2pcs gland cable plates;
-mounting plate;
-the accesories of plinth 100mm can be supplied separately according to the client's requirement.
TPX series stainless steel control desk
Material : stainless steel AISI304 or AISI316
Thickness of sheet steel -body: 1.5mm
-front door: 2.0mm
-upper cover: 2.0mm
-galvanized mounting plate: 2.5mm;
Supply include -control desk;
-front door with lock system;
-upper cover with cover stop 2pcs;
-2pcs gland cable plates;
-mounting plate;
-the accessories of plinth 100mm can be supplied separately according to the client's requirement.
