Quick Details
-
Brand Name:
-
WF-Tailai
-
Model Number:
-
TL- space truss
-
surface treatment:
-
painting or hot dip galvanizing
-
Size:
-
up to customer's requirement
-
installation:
-
assigning our engineer on site
-
Design:
-
available and free
Quick Details
-
Grade:
-
Q235,Q345
-
Tolerance:
-
±1%
-
Place of Origin:
-
China
-
Brand Name:
-
WF-Tailai
-
Model Number:
-
TL- space truss
-
surface treatment:
-
painting or hot dip galvanizing
-
Size:
-
up to customer's requirement
-
installation:
-
assigning our engineer on site
-
Design:
-
available and free
Product Description
| ITEM | MEMBER NAME | SPECIFICATION |
| Main Steel Frame | Column | Q235, Q355 Welded /Hot Rolled H Section Steel |
| Beam | Q235, Q355 Welded /Hot Rolled H Section Steel | |
| Secondary Frame | Purlin | Q235 C or Z Type Purlin |
| Knee Brace | Q235 Angle Steel | |
| Tie Bar | Q235 Circular Steel Pipe | |
| Strutting Piece | Q235 Round Bar | |
| Vertical & Horizontal Bracing | Q235 Angle Steel or Round Bar | |
| Cladding System | Roof Panel | EPS / Rock Wool / Fiber Glass/PU Sandwich Panel or Corrugated Steel Sheet Panel |
| Wall Panel | Sandwich Panel or Corrugated Steel Sheet Panel | |
| Window | Aluminiumn Alloy Window | |
| Door | Sliding Sandwich Panel Door / Rolling Shutter Door | |
| Skylight | FRP | |
| Accessories | Rainspout | PVC |
| Gutter | Made of Steel Sheet / Stainless Steel | |
| Connection | Anchor Bolt | Q235,M24/M45 etc |
| High Strength Bolt | M12/16/20,10.9S | |
| Normal Bolt | M12/16/20,4.8S | |
| Wind Resistance | 12 Grades | |
| Earthquake-Resistance | 9 Grades | |
| Surface Treatment | Alkyd Paint.EpoxyZinc Rich Paint or Galvanized | |
Main Features
1) Enviromental friendly
2) Lower cost and maintenance
3) Long using time up to 50 years
4) Stable and earthquake resistance up to 9 grade
5) Fast construction, time saving and labor saving
6) Good appearance
