Quick Details
-
winding head:
-
4-8
-
coil holder:
-
4-10
-
machine color:
-
all kinds according to customer
-
working type:
-
horizontal
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinkang
-
Model Number:
-
RX01
-
winding head:
-
4-8
-
coil holder:
-
4-10
-
machine color:
-
all kinds according to customer
-
working type:
-
horizontal
Product introduction(JK-RX01):
This machine can be made multi-type, multi-layer winding, is able to wind 1-10 wires at the same time, can automatically groove Automatic tap, equipped with two square shaft winding used alternately, its adaptable wire diameter ranges from ¢25 to ¢180 mm.
Starting winding point , linewidth, winding speed, slow start, slow stop, row line direction, parking on both ends
Automatic homing, automatic starting, automatic slot, auto tap, etc can be set automatically.
Ribbon cable on the slider is equipped with 1-10 of pay-off arm, high and low Angle can be arbitrarily adjusted;
Equipped with 1-20 ¢210 mm * 320 mm steel barrels;
Equipped with a complete set of 16 mm * 16 mm * 625 mm square shaft;
High efficiency and easy operation;
OEM available, same quality much lower price.
Technical Data:
| Wire diameter range | 0.1-1.0mm |
| Winding width | ≤190mm |
| Winding diameter | ≤280mm |
| Effective distance between winding shafts | 520mm |
| Distance of classes | ≤190mm |
| Max. winding speed | 3000RPM |
| Air pressure | 0.4-0.7MPa |
| Power supply | 220v/50Hz |
| Power | 0.75KW |
| Dimension (L*W*H) | 1420mm*1300mm*1500mm |
| Weight | ≈550kg / ≈700kg |
|
All the technical parameters can be designed and manufactured according to customer's request. |
|
Product show (JK-RX01):
Product details (JK-RX01):
wire brake sensor
CNC controller
winding heads
winding tooling
The outer packing(JK-RX01):
Other types of products:
Certificate:
Company profile:
Changzhou JinKang Electromechanical Group is one of the high-tech key enterprises which specialize in designing, producing and selling motor manufacturing equipments in China. The company now has nearly 300 employees, including more than 50 engineers and technicians, with the building area about 20,000 square meters and a hundred sets of advanced production and test equipments. It is now qualified for designing and manufacturing full production line (starts from coil winding to final forming of a stator) for AC motors such as home appliance motor, industrial medium and small motors, pump motor, rolling door motor and automobile motor etc. In 2008, Jinkang passed the certification of ISO9001:2000 Quality Management System.
