cotton pad make up rolled face cleaning tissue towel winding making machine

cotton pad make up rolled face cleaning tissue towel winding making machine

Raw material diameter: 800mm
Finished product diameter: 250mm
Punching device: automatic punching (adjustable)
Perforating knife tooth pitch: 10:1mm
Production speed 300 rolls/hour
Rated voltage 380V
Rated frequency 50Hz
Total power 2.5kw
Dimensions: length 2200mm*width 1200mm*height 1500mm
Equipment weight: about 500kgs
The working principle of the equipment: raw material jumbo synchronous conveying→folding→punching→automatic rewinding→stop when the winded rolls reached to the setted winding quantity.

Automatic toilet rolls production tissue paper rewinding machine prices

1 set automatic plc control tissue paper embossing rewinder

1 set automatic toilet logs accumulator

1 set single or double channel toilet log saw

1 set automatic single toilet rolls packing machine

Toilet tissue log saw will be connected with tissue paper rewinding machine by automatic toilet logs accumulator.

Raw tissue paper rewinding machine for toilet rolls production

1) speed: 180-210 meter/min
2) raw tissue paper width: 1350, 1750,2100,2300, 2500,2850,3000,3500mm
3) jumbo roll diameter: 1100mm
4) raw tissue paper core diameter: 76.2mm
5) finihed roll diameter:60-150mm

6) perforating: 4 pieces screw perforating blades

7) unwinding: 1-3 ply( optional)

8)Single side steel to steel embossing unit

Features of our 1-3 ply tissue paper rewinding machine

1) advanced PLC programmable contro, the winding tissue paper can be tight at the begainning o the reeling and them getting loose, to avoid the problems taht the cores are loose from the rolls after long time storage.

2) variable speed adjustment

3) loading and placing of the cores by labor, saving time, and reduce the machine covering area.

4) three layer back stands pneumatically wide belt paper, unwiding driving and individual web tenson control unit for each jumbo toilet paper roll

5) with high precision screwy perforation knife.

Toilet rolls production toilet roll logs accumulator

Suitable for: 1575, 1880, 2700, 3000mm width rewinded toilet tissue logs

Large storage capacity, and can be matched with two sets automatic tissue paper rewinding machine and 1 set double channel toilet log saw

Roll storage quantity : can be adjusted according to your tissue paper roller's diameter

PLC control sensor, automatic changing tissue rollers, improve the whole tissue paper production lines production capacity.

Automatic toilet rolls packing machine

Delivery of our tissue paper manufacturing machines

Plastic film wrap the tissue paper machines, then load into container

30% T/T prepayment. 70% before delivery from Qingdao Seaport

The service that you can enjoyed from us for tissue paper manufacturing machines
