Quick Details
-
Model Number:
-
1507-12126-20.TH Series
Quick Details
-
Door Type:
-
Glass door, Wood door, Steel door, Stainless Steel door, Aluminum door, Brass door
-
Network:
-
wifi, bluetooth, TCP, Ip, SDK
-
Place of Origin:
-
Beijing, China
-
Model Number:
-
1507-12126-20.TH Series
·Technical Parameter
| No. | Items | Specification |
| 1 | Material | Housing PA66, Zinc die handle |
| 2 | Color | Black |
| 3 | Rated voltage | DC 12V or 5V( Can be Customize d) |
| 4 | Operating voltage | DC 12V ±20%( Can be Customized) |
| 5 | Power | 5W |
| 6 | Rated current | ≤4 00MA |
| 7 | IP Rate | IP54 |
| 8 | Working Environment | Temperature:-40 ~+65℃ Humidity:5 ~ 90% |
| 9 | Storage Environment | Temperature: -40 ~+80℃ Humidity: 0 ~ 90% |
| 10 | Card Read Signal Distance | 0-15mm |
| 11 | Communication Interface | RS485/DO |
| 12 | Critical Frequency | 13.56Mhz |
| 13 | Warranty | 5years |
· Features
· l Diversified access ways, Authority management, and Record query.
· l D riving by electric motor ,More safe, stabilization and reliance
· l Easy to use, install and maintain.
1. Cabinet intelligent locks can implement functions such as diversified access ways, user authority management, query of lock operation records, and intelligent management of lock tasks.
2. Adopt modular design, no special control unit and readers, integrated with password button, card readers, communication modules, fingerprint identification modules, RS485 communication modules
3. Driven by high reliability motor and adopted high stability hardware design to guarantee the stability and reliability of the product
4. High versatility of the cabinet.The lock is suitable for APC, Emerson, Vertiv, Eaton, Toten, Panduit, CPI and etc.
5. The electronic lock can connect various intelligent PDU or control unit for remote communication and control.
1 , Unlocking operation: When the lock opens successful, the buzzer sounds and the indicator light turns green. Then lift the handle and turn it, the locking mechanism like cam and rod can be driven and complete the opening action.
2, Locking operation: Press the handle back to the base .
