Ai with ADAS (Advanced Driver Assistance System)
- Product Details
- {{item.text}}
Quick Details
-
Type:
-
4 CH MOBILE DVR
-
Video input:
-
4CH Aviation Connector
-
Storage:
-
2x256 SD CARD
-
Language:
-
English/Customizable
-
Optional Function:
-
4G GPS WIFI G SENSOR
-
AI:
-
DSM/ADAS/n
-
Video Output:
-
1 Channel Video Output
-
Power Supply:
-
8V-36V
-
Resolution:
-
1080P/960P/720P/D1/CIF
-
Video Compression Format:
-
H.265
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RECODA
-
Model Number:
-
M605
-
Type:
-
4 CH MOBILE DVR
-
Video input:
-
4CH Aviation Connector
-
Storage:
-
2x256 SD CARD
-
Language:
-
English/Customizable
-
Optional Function:
-
4G GPS WIFI G SENSOR
-
AI:
-
DSM/ADAS/n
-
Video Output:
-
1 Channel Video Output
-
Power Supply:
-
8V-36V
-
Resolution:
-
1080P/960P/720P/D1/CIF
-
Video Compression Format:
-
H.265
Product Description
MDVR+AI
AI with DSM to detect Fatigure driving /Distracted Driving / cell phone use/Smoking
MDVR+AI
,with smart
DSM ,ADAS ,
vehicle license plate recognition
Our MDVR systems help you to give proof for accident and insurance, and they are perfect for vehicle surveillance and fleet managements.
applied with car cameras used for vehicle monitoring in bus, taxi, school bus, truck, tour bus, tanker truck, escort car etc.
Detailed Images
8-10 Seconds Data Protection
The MDVR supports 8-10 seconds delay recording to protect the data not to lost when the car battery turn off
4 Channels FULL HD 1080P Recording
Widely used for vehicle monitoring in bus, taxi, school bus, truck, tour bus, tanker truck, escort car etc.
Product Presentation
|
Item
|
|
|
Parameter
|
|
|||
|
OS
|
|
|
Linux
|
|
|||
|
Language
|
|
|
Chinese/English/Customized
|
|
|||
|
Video Compression
|
|
|
H.265/H.264
|
|
|||
|
OSD
|
|
|
Overlays information such as date time and vehicle ID
|
|
|||
|
GUI
|
Graphical User Interface
|
|
Setup system parameters with the remote control.
|
|
|||
|
Video Record System
|
Video Input
|
|
4CH AHD input
|
|
|||
|
|
|
|
aviation connector, 1.0Vp-p, 75Ω
|
|
|||
|
|
Video Output
|
|
1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,
|
|
|||
|
|
|
|
4CH Screen
|
|
|||
|
|
Preview
|
|
Support 1 channel and 4 channels preview.,Support Manual
|
|
|||
|
|
|
|
/Alarm Trigger full screen preview
|
|
|||
|
|
Resolution
|
|
1080P/720P/D1/HD1/CIF, MAX:4 channels of 1080P
|
|
|||
|
|
Video Quality
|
|
0-7 levels, 0 is the highest level.
|
|
|||
|
|
Video Standard
|
|
PAL: 100f/s , CCIR625 line,50field;
|
|
|||
|
|
|
|
NTSC: 120f/s, CCIR525 line,60field;
|
|
|||
|
|
|
|
CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional;
|
|
|||
|
|
|
|
HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional;
|
|
|||
|
|
|
|
D1: 800Kbps ~ 3Mbps, 8 level video quality optional;
|
|
|||
|
|
|
|
720P: 4Mbps-6Mbps, multi level video quality optional
|
|
|||
|
|
|
|
1080P:4Mbps-8Mbps,multi level video quality optional
|
|
|||
|
|
Record Mode
|
|
The default setting is auto recording after power on.
|
|
|||
|
|
|
|
Timed recording,
|
|
|||
|
|
|
|
alarm trigger recording and manual recording are supported.
|
|
|||
|
Audio
|
Audio Input
|
|
4CH ,Aviation Plug
|
|
|||
|
|
Audio Output
|
|
1CH,Aviation Plug
|
|
|||
|
|
Compression
|
|
G.726 compression, 8KB/s speed
|
|
|||
|
Alarm Input
|
|
|
4 Ch Alarm Input, kinds of alarm linkage support
|
|
|||
|
Alarm Output
|
|
|
2CH Alarm Output
|
|
|||
|
Position
|
|
|
Support Built GPS/BD Module
|
|
|||
|
Interface
|
|
|
1CH RS232 to connect OBD, POS/Fuel Sensor/LED Advertisement Connection
|
|
|||
|
|
|
|
|
|
|||
|
|
|
|
1CH 485 Interface,Connect PTZ Camera
|
|
|||
|
G-Sensor
|
|
|
Support G-sensor
|
|
|||
|
Storage
|
|
SD
|
Dual SD Card,each max 128GB SD Card loop recording
|
|
|||
|
|
|
Upgrade
|
Support SD Card updating
|
|
|||
|
|
|
File Format
|
H.265/H.264
|
|
|||
|
|
|
File System
|
Special FAT32 File System
|
|
|||
|
Video Playback
|
|
Video Search
|
Search By Record Time/Record Type etc
|
|
|||
|
|
|
Playback
|
Max support 4CH Replay /Stop/Fast/Slow at same time
|
|
|||
|
|
|
|
Support forward and backward play
|
|
|||
|
|
|
|
at the speed of: x 2,x4,x8,x16.
|
|
|||
|
Voltage &
|
|
Power Management
|
Wide Voltage.Support Timed/Delay off
|
|
|||
|
Power
|
|
Voltage Input
|
DC:+10V ~ +36V
|
|
|||
|
|
|
Voltage Output
|
+12V@2.5A,+5V@2.5A
|
|
|||
|
|
|
Power Consumption
|
Normal Working ＜5W
|
|
|||
|
Working Environment
|
|
Temperature
|
-20℃ to +70℃
|
|
|||
|
|
|
Humidity
|
20% to 80%
|
|
|||
|
Security
|
|
Password
|
User/Admin 2 Level Different Password
|
|
|||
|
others
|
|
Size
|
154(W) x42(H) x138(D) mm
|
|
|||
|
|
|
Net Weight
|
0.55 kg
|
|
|||
Certificate
Packing&Shipping
