Quick Details
-
Remote Controlled:
-
Yes
-
Overheating Protected:
-
Yes
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Adjustable Thermostat:
-
Yes
-
Certification:
-
CE
-
Remote Controlled:
-
Yes
-
Overheating Protected:
-
Yes
bioethanol fireplace
|
Alcohol consumption of oxygen and produce carbon dioxide combustion conditions |
|||||||
|
1 liter of alcohol |
Oxygen : 1165 liter/1.165 CBM |
||||||
|
|
Generate Carbon dioxide : 0.78 CBM, Exothermic 8.3KW |
||||||
|
Technical parameters of Remote control fireplace |
|||||||
|
RX-500 |
RX-1000 |
||||||
|
Ignition method |
High Energy Low intensity Delay electrode Ignition |
Ignition method |
High Energy Low intensity Delay electrode Ignition |
||||
|
Fuel |
75-95% Ethanol |
Fuel |
75-95% Ethanol |
||||
|
Fuel consumption |
0.6-1 liter/H |
Fuel consumption |
0.9-1.5 liter/H |
||||
|
Fuel tank capacity |
25X20X20CM,10 liter |
Fuel tank capacity |
60X20X18CM,21 liter |
||||
|
Heating output power |
2-3 kw |
Heating output power |
6-8 kw |
||||
|
Noise |
20-40dB |
Noise |
20-40dB |
||||
|
Water pump |
Low Noise Micropower piezoelectric pump |
Water pump |
Low Noise Micropower piezoelectric pump |
||||
|
Continuous burn time |
13-16 H |
Continuous burn time |
15-18 H |
||||
|
Dimensions L*W*H |
Panel |
500X250X0.3MM |
Dimensions L*W*H |
Panel |
1000X250X0.3MM |
||
|
|
Base |
450 X2 0 0X2 35 MM |
|
Base |
9 50 X200X2 35 MM |
||
|
Weight |
32 |
Weight |
43.5 |
||||
|
Case Material |
Stainless steel / iron powder |
Case Material |
Stainless steel / iron powder |
||||
|
Supply voltage/ power |
220V, 50HZ |
Open :66w Working : 13w Fueling : 12w |
Supply voltage/ power |
220V, 50HZ |
Open :66w Working : 13w Fueling : 12w |
||
|
Configuration |
High temperature automatic power-off protection,prevent overflow protection, lack of fuel alarm, oil Full alert, power tilt, remote control switches, cabinet switches, fuses, Power Cord |
|
|
||||
|
Optional |
CO2 alarm, exhaust port, an external LCD panel for Ventilate |
|
|
||||
|
Attachment |
Manual,remote control, hoses, filters |
Attachment |
Manual,remote control, hoses, filters |
||||
Intelligent fireplace with ordinary fireplace has essentially different . Intelligent fireplace is an product that combine advanced microcomputer intelligent control technology and exquisite patented high-tech sheet metal structural , not only first-class combustion, but also truly people-oriented, control and security is the most advanced all over the world . combustion amount of alcohol use microcomputer to control the precise calculation of the supply per second, every minute , during combustion process continuously monitors the furnace and ambient data, in case any data abnormal alarm will immediately and automatically cut off the supply of alcohol, stop burning, shut down the entire system, to ensure maximum use of the user security .
2. How long the warranty period Intelligent fireplace?
The warranty period is one year, lifetime service after the warranty expires, supply of spare parts and maintenance fees in accordance with the market price.
3. Easy maintenance?
If accidental damage, we will replace the fireplace circuit, Maintenance is very simple.
Safe use in accordance with the requirements of the specification, is not easily damaged .
