Quick Details
-
Brand Name:
-
HM
-
Model Number:
-
HM-MSTtype-2.54P
-
Max. Current:
-
25MA
-
operating force:
-
8N max
-
contact resistance:
-
500MΩ max.at
-
insulation resistance:
-
100MΩ min at 500VDC
-
capacitance:
-
5PF max
-
materials:
-
copper PBT
-
circuit:
-
single pole double throw
-
Dielectric strength:
-
500VAC/1minute
-
electrica life:
-
2000operations cycles per switch 25mA,24VDC
-
operating temperature:
-
-25-+70C
-
Product name:
-
DIP SWITCH
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
24V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HM
-
Model Number:
-
HM-MSTtype-2.54P
-
Max. Current:
-
25MA
-
operating force:
-
8N max
-
contact resistance:
-
500MΩ max.at
-
insulation resistance:
-
100MΩ min at 500VDC
-
capacitance:
-
5PF max
-
materials:
-
copper PBT
-
circuit:
-
single pole double throw
-
Dielectric strength:
-
500VAC/1minute
-
electrica life:
-
2000operations cycles per switch 25mA,24VDC
-
operating temperature:
-
-25-+70C
-
Product name:
-
DIP SWITCH
low profile type 8 way dip switch with flat actuator
Features |
|
Insulation resistance: |
1000M Ω min,at DC 500V.
|
Contact resistance: |
30m Ω max,at DC 100mA. |
Current Rating: |
1 AMP. |
Dielectric withstanding |
|
Voltage: |
AC 500V For 1 minute . |
Operating temperature: |
-55 ° C-85 ° C. |
Contact: |
Phosphor Bronze |
Housing: |
PBT & 30% Glass Fiber(UL 94V-0) |
Q1: Are you a factory or trader?
we are a factory.
Q2: Why choose your company?
1.more than ten years manufacture experience about more kinds of switch
2.good quality,competitive price,fast delivery time
3.more switch type choosed,such as keyboard switch,rotary switch,rocker switch, push button switch, slide switch,dip switch,micro switch,tact switch,ac/dc socket and connector.
4.Design and Develop new mould depends on clients requirement
5.The best after-sale service
6.Anytime you need help ,please contact with us we keep online all the time.
Q3: How to get the samples and quote the best price soon?
we need to know more details about the products you inquired,for example
what functions?what size?what rating?where the type to be used?
we free to offer the samples
Q4.How about the delivery time?
Gernally speaking it is need 2 weeks if your quantity below 10K pcs or it depends on your quantity to confirm the time.
Q5:How about the package of the goods?
we often package the goods more safty, both inner box and outside cartons
more related product details,please feel free to contact with us!
