Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HYCRANES
-
Weight (KG):
-
2200 kg
-
Product Name:
-
Single Girder Overhead Crane
-
Lifting Capacity:
-
1 ton~20 ton
-
Lifting mechanism:
-
Europe type hoist
-
Lifting speed:
-
0.8/5m/min
-
Industrial voltage:
-
380v50hz3p or customers' requirements
-
Control method:
-
Pendant+Remote(Customized)
-
Working duty:
-
A5
-
Working Temperature:
-
-25~+40℃
-
Application:
-
factory/warehouse logistics/freight yard
-
Color:
-
Customers' Requirements
Quick Details
-
Max. Lifting Height:
-
up to you
-
Rated Lifting Moment:
-
different
-
Span:
-
5.5~30m
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HYCRANES
-
Weight (KG):
-
2200 kg
-
Product Name:
-
Single Girder Overhead Crane
-
Lifting Capacity:
-
1 ton~20 ton
-
Lifting mechanism:
-
Europe type hoist
-
Lifting speed:
-
0.8/5m/min
-
Industrial voltage:
-
380v50hz3p or customers' requirements
-
Control method:
-
Pendant+Remote(Customized)
-
Working duty:
-
A5
-
Working Temperature:
-
-25~+40℃
-
Application:
-
factory/warehouse logistics/freight yard
-
Color:
-
Customers' Requirements
Products Description
Description:
Europe overhead crane advanced designed crane for the low headroom and high lifting height demands. It has many advantages such as: Strong rigidity, light dead weight, outstanding structure design, long working lift etc. It could save your factory space and investment effectively.Its technology is advanced and design is based on international standard: DIN (Germany),FEM (Europe), and ISO (International) The all motions of this overhead crane are double speeds, the lifting motor is double speed type,the cross travelling motor and long travelling motor are controled by frequency inverte It could be widely used to handle materials in many industries' workshop
and warehouse,such as manufacture processing, warehouse, storage, paper mill, electronics industries workshopand other material handling situation
and warehouse,such as manufacture processing, warehouse, storage, paper mill, electronics industries workshopand other material handling situation
Advantage:
1. Overload protection: If the material is over the capacity, the crane will give a sharp warning for protection itself
2. Emergency brake: If the operation staff encounter some emergency situation, we could start the emergency brake system to
protection the related treasure.
3. Control Method: Room control or remote control to avoid any injure to the operation staff
4. Main lifting motor: with thermal protection and currency protection.
5. Hooks with latch
6. Rubber buffers
7. Protective earthing
8. Crane switch and travel end switch
9. Sub-assemblies characteristic are tested before assemly.
10.All cranes must be pre-assmebled and tested before leaving factory and offer the certification of test
2. Emergency brake: If the operation staff encounter some emergency situation, we could start the emergency brake system to
protection the related treasure.
3. Control Method: Room control or remote control to avoid any injure to the operation staff
4. Main lifting motor: with thermal protection and currency protection.
5. Hooks with latch
6. Rubber buffers
7. Protective earthing
8. Crane switch and travel end switch
9. Sub-assemblies characteristic are tested before assemly.
10.All cranes must be pre-assmebled and tested before leaving factory and offer the certification of test
Product Paramenters
|
Item
|
Data
|
|
Capacity
|
1-12.5t
|
|
Span
|
7.5-25.5m
|
|
Lifting height
|
6-12m
|
|
Lifting speed
|
5/0.8m/min
|
|
Cross travelling speed
|
2-20m/min
|
|
Long travelling speed
|
2-45m/mim
|
|
Working class
|
ISOA3-A5/FEM1AM-FEM2M
|
|
Power source
|
As your demands
|
|
Other
|
According to your specific usage, specific model and design will offer
|
