Quick Details
-
Model Number:
-
M16-8A
-
Max. Current:
-
10A
-
Max. Working Pressure:
-
1Mpa
-
Starting Pressure:
-
1.5bar or 2.2bar
-
Max Allowable Pressure:
-
10bar
-
Frequency:
-
50/60HZ
-
Max Ambient Temperature:
-
40℃
-
Max Liquid Temperature:
-
60℃
-
Protection Degree:
-
ip65
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
110-220V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
cntopsun/ODM
-
Model Number:
-
M16-8A
-
Max. Current:
-
10A
-
Max. Working Pressure:
-
1Mpa
-
Starting Pressure:
-
1.5bar or 2.2bar
-
Max Allowable Pressure:
-
10bar
-
Frequency:
-
50/60HZ
-
Max Ambient Temperature:
-
40℃
-
Max Liquid Temperature:
-
60℃
-
Protection Degree:
-
ip65
-
Certification:
-
CE
Product Description
TECHNICAL DATA
1. Starting Pressure: 1.5bar or 2.2bar
2. Max Rated Current: 10A
3. Max Allowable Pressure: 10bar
4. Rated Voltage: 110V or 220V
5. Frequency: 50/60Hz
6. Max Ambient Temperature: 40℃
7. Max Liquid Temperature: 60℃
8. Protection Degree: IP65
DESCRIPTIONS
1. Stop and start the pump automatically
2. Stop the pump in the case of water shortage
3. After power cut off, it can restart the pump automatically when the power on
4. Forced start
5. Joint screw: G1"male
OPTIONS
1. Optional function
A: Starting pressure is adjustable during installation, adjustment range: 1.5bar-3.0bar.
B: Automatic restart after water shortage, the restart interval time is 8S,30S,1minute, 10minutes, 30minutes, 1hour, 2 hours recycle.
The above 2 options function can be achieved at the same time, or you can choose just one.
2. Color.
3. G1"plastic pipe joint for a quick connection to water pump.
4. Power cable length
| BOX SIZE(CM) | 14.5x15x19 |
| CARTON SIZE(CM) | 614x47.5x21 |
| PCS/CTN | 12 |
| N.W.(KGS) | 14.60 |
| G.W.(KGS) | 15.80 |
| 20GP QUATITIES(PCS) | 5976 |
1. Starting Pressure: 1.5bar or 2.2bar
2. Max Rated Current: 10A
3. Max Allowable Pressure: 10bar
4. Rated Voltage: 110V or 220V
5. Frequency: 50/60Hz
6. Max Ambient Temperature: 40℃
7. Max Liquid Temperature: 60℃
8. Protection Degree: IP65
DESCRIPTIONS
1. Stop and start the pump automatically
2. Stop the pump in the case of water shortage
3. After power cut off, it can restart the pump automatically when the power on
4. Forced start
5. Joint screw: G1"male
OPTIONS
1. Optional function
A: Starting pressure is adjustable during installation, adjustment range: 1.5bar-3.0bar.
B: Automatic restart after water shortage, the restart interval time is 8S,30S,1minute, 10minutes, 30minutes, 1hour, 2 hours recycle.
The above 2 options function can be achieved at the same time, or you can choose just one.
2. Color.
3. G1"plastic pipe joint for a quick connection to water pump.
4. Power cable length
PACKING INFORMATION
Our Services
|
1. Your inquiry will be replied within 24 hours. |
|
2. We offer you professional service in fluent English. |
|
3. Keep the mass production as the sample in high quality |
|
4. Freight forwarder: faster,safer, and convenient. |
|
5. Quality: we have QC on each process,provide high quality products. |
