- Product Details
- {{item.text}}
Quick Details
-
Battery Energy(kWh):
-
≤30kWh
-
Total Horsepower(Ps):
-
≤100Ps
-
Drive Motor:
-
Single
-
Model Number:
-
SD01CA
-
Place of Origin:
-
Hubei, China
-
Dimension:
-
4046mm*1737mm*1606mm
-
Total electricity(kW*h):
-
44.5
-
Overall Dimensions (mm):
-
4046mm*1737mm*1606mm
-
Control system:
-
Brake energy recovery
-
Total electricity:
-
44.5kw/h
-
Battery:
-
Lithium Battary
-
Brake (Front / Rear ):
-
Vented Disc / disc
-
Tire:
-
205 /55 R16
-
Seat Capacity:
-
4 seats
-
Maximum speed:
-
130km/h
Quick Details
-
Brand Name:
-
suda
-
Battery Type:
-
Lithium
-
NEDC Max. Range:
-
101~200 km
-
Battery Energy(kWh):
-
≤30kWh
-
Total Horsepower(Ps):
-
≤100Ps
-
Drive Motor:
-
Single
-
Model Number:
-
SD01CA
-
Place of Origin:
-
Hubei, China
-
Dimension:
-
4046mm*1737mm*1606mm
-
Total electricity(kW*h):
-
44.5
-
Overall Dimensions (mm):
-
4046mm*1737mm*1606mm
-
Control system:
-
Brake energy recovery
-
Total electricity:
-
44.5kw/h
-
Battery:
-
Lithium Battary
-
Brake (Front / Rear ):
-
Vented Disc / disc
-
Tire:
-
205 /55 R16
-
Seat Capacity:
-
4 seats
-
Maximum speed:
-
130km/h
Products Description
|
Main parameter
|
|
|
|
Model
|
SD01CA
|
|
|
Class
|
A class
|
|
|
Motor power and model
|
Rated power 40kW ,peak power 80kW ,AC
|
|
|
|
permanent magnet synchronous motor
|
|
|
Motor rated torque / peak torque (N·m)
|
128 /240
|
|
|
Motor rated speed /maximum working speed (rpm)
|
3357 /9000
|
|
|
Total electricity(kW*h)
|
44.5
|
|
|
Battery pack rated voltage (v)
|
329.4
|
|
|
Control system
|
Brake energy recovery
|
|
|
Maximum speed (km/h)
|
130
|
|
|
Mileage for Single Charge (km)
|
On Road 305
|
|
|
|
440 Constant Speed
|
|
|
Dimension and Weight
|
|
|
|
Length / Width / Height (mm)
|
4046 /1737 /1606
|
|
|
wheel-base (mm)
|
2500
|
|
|
Front / rear tyre base (mm)
|
1500 / 1495
|
|
|
Approach angle (°)
|
16.5
|
|
|
Departure angle (°)
|
22.6
|
|
|
Minimum ground clearance (mm)
|
125
|
|
|
Minimum turning radius (m)
|
4.8
|
|
|
curb weight (kg)
|
1390
|
|
|
Maximum total weight (kg)
|
1765
|
|
|
Chassis specification
|
|
|
|
Suspension system (Front / Rear )
|
McPherson independent suspension / Longitudinal arm torsion beam semi independent suspension
|
|
|
|
|
|
|
Brake (Front / Rear )
|
Vented Disc / disc
|
|
|
Tyre specification
|
205 /55 R16
|
|
