Quick Details
-
Engine Brand:
-
CHANGCHAI
-
Travel Speed:
-
0~9km/h
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Kudat
-
Dimension(L*W*H):
-
3170/1500/2580 mm
-
Drum diameter:
-
860 mm
-
Drum:
-
1 steer drum(front)+4 rubber drums(rear)
-
Exciting Force:
-
42 kN
-
Rolling width:
-
1350mm
-
Steel wheel static linear load:
-
167N/cm
-
Rubber wheel static linear load:
-
210N/cm
-
Vibration frequency:
-
55hz
-
Theoretical amplitude of vibration:
-
0.5mm
-
Tire specification:
-
10.5 / 80(smooth)
-
Engine power/speed:
-
36.8/2400kW/r/min
-
Min ground clearance:
-
230 mm
-
wheelbase:
-
2320 mm
-
min turning radius:
-
4850 mm
Quick Details
-
Type:
-
tire combined roller
-
Power:
-
40kw
-
Weight:
-
4.5ton
-
Engine Brand:
-
CHANGCHAI
-
Travel Speed:
-
0~9km/h
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Kudat
-
Dimension(L*W*H):
-
3170/1500/2580 mm
-
Drum diameter:
-
860 mm
-
Drum:
-
1 steer drum(front)+4 rubber drums(rear)
-
Exciting Force:
-
42 kN
-
Rolling width:
-
1350mm
-
Steel wheel static linear load:
-
167N/cm
-
Rubber wheel static linear load:
-
210N/cm
-
Vibration frequency:
-
55hz
-
Theoretical amplitude of vibration:
-
0.5mm
-
Tire specification:
-
10.5 / 80(smooth)
-
Engine power/speed:
-
36.8/2400kW/r/min
-
Min ground clearance:
-
230 mm
-
wheelbase:
-
2320 mm
-
min turning radius:
-
4850 mm
Product Description
Specification
|
Standard configuration
|
CHANGCHAI Engine(GB II), Poclain Pump & Motor for travelling system; TIANJI Pump & Motor for vibrating system
|
|
Applicable Industries
|
Construction works , Roads
|
|
Oil tank capacity
|
130L
|
|
Condition
|
New
|
|
Type
|
drum combined roller
|
|
Travel Speed
|
0~9km/h
|
|
Grade Ability
|
30%
|
|
Place of Origin
|
China
|
|
Province
|
Hubei
|
|
Brand Name
|
Kudat
|
|
Power
|
40kw
|
|
Dimension(L/W/H)
|
3170/1500/2580 mm
|
|
Weight
|
4.5ton
|
|
Warranty
|
1 Year
|
|
Hydraulic Pump Brand
|
POCLAIN
|
|
Hydraulic Valve Brand
|
POCLAIN
|
|
Engine Brand
|
CHANGCHAI
|
|
UNIQUE SELLING POINT
|
High operating efficiency
|
|
Drum diameter
|
860 mm
|
|
Drum
|
1 steel drum(front)+4 rubber smooth drums(rear)
|
|
Exciting Force
|
42 kN
|
|
Machinery Test Report
|
Provided
|
|
Video outgoing-inspection
|
Provided
|
|
Marketing Type
|
New Product 2020
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
Pressure vessel, Motor, Other, Pump, Engine, Gearbox
|
|
Rolling width
|
1350mm
|
|
Steel wheel static linear load
|
167N/cm
|
|
Rubber wheel static linear load
|
210N/cm
|
|
Vibration frequency
|
55hz
|
|
Theoretical amplitude of vibration
|
0.5mm
|
|
Tire specification
|
10.5 / 80(smooth)
|
|
Engine power/speed
|
36.8/2400kW/r/min
|
|
Min ground clearance
|
230 mm
|
|
wheelbase
|
2320 mm
|
|
min turning radius
|
4850 mm
|
Packing & Delivery
standard export packing, wood container/metal frame
