login server can be used to manage the Internet of things traffic and turn on and off hot spots.
Transmission power: 20dBm(802.11b), 18dbm (802.11g), 15dbm (802.11n).
Receiving sensitivity -90dbm (802.11b),-72 dBm(802.11g)-72 dBm(802.11n).
Iot band LTE B1 / B3 / B7 / B8 B38 / B39 / B40 / B41
WCDMA 2100 MHZ or 900 MHZ
The td-scdma SWCDMA B34 B39GSM/GPRS/EDGE / 900/1800 MHZ,
Transmission rate: fdd-lte/td-lte downlink 150MBPS, uplink 50MBPS
WCDMA under the behavior of 21MBPS, up 5.76MBPS, td-scdma downlink 2.8MBPS, up 2.2MBPS.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
XBPA-5100G
-
Place of Origin:
-
Guangdong, China
-
Certification:
-
iso
-
network interface:
-
RJ45 + SIM
-
chip:
-
High-speed industrial-grade chip
-
Support agreement:
-
TCP/IP, UDP, IGMP(multicast), SIP, FTP, ARP
-
bandwidth:
-
S/8KB
-
Audio mode:
-
16-bit CD quality
-
Output way:
-
4 ~ 16 Ω resistance output, 70 v / 100 v constant voltage output
-
Environmental humidity:
-
20% ~ 80% relative humidity, no condensation
-
Product Name:
-
wireless network audio amplifier
Quick Details
-
Type:
-
Professional Amplifier
-
Channels:
-
4
-
Brand Name:
-
XBPA
-
Model Number:
-
XBPA-5100G
-
Place of Origin:
-
Guangdong, China
-
Certification:
-
iso
-
network interface:
-
RJ45 + SIM
-
chip:
-
High-speed industrial-grade chip
-
Support agreement:
-
TCP/IP, UDP, IGMP(multicast), SIP, FTP, ARP
-
bandwidth:
-
S/8KB
-
Audio mode:
-
16-bit CD quality
-
Output way:
-
4 ~ 16 Ω resistance output, 70 v / 100 v constant voltage output
-
Environmental humidity:
-
20% ~ 80% relative humidity, no condensation
-
Product Name:
-
wireless network audio amplifier
Product Description
|
Product Name
|
Intelligent power 2/3/4G wireless network audio amplifier built-in 8-way hot WIFI
|
|
Material
|
Alumina
|
|
Function
|
Remote wireless network broadcast
|
-
Product performance description
Details Images
Resistance (4-16 Ω) and constant voltage (70 v, 100 v) output power 100 w to 650 w.Wireless Internet of things card access, built-in 8-way hot WIFI, WEB Silver alumina wire-drawing panel, standard 19-inch frame design, industrial grade 3.4-inch LCD display, 10 buttons.
SMT Adopt tunnel type air - cooled structure.
With adaptive cooling system, according to the input audio sensitivity to adjust the working frequency of heat dissipation, no audio input delay of 15S automatic standby, audio start immediately.
AUX and MIC input ports, with independent volume and bass adjustment, and support for off-line pager function.
1 channel iot hardware audio decoding module, supporting TCP/IP, UDP, IGMP(multicast), SIP, FTP, ARP protocol, realizing 2G/3G/4G wireless network transmission of 16-bit CD audio signal.It takes up bandwidth S/8KB.
Built-in intelligent power management, no music or call, automatically cut off the power amplifier, power amplifier automatically open when there is a signal; It has the function of programming pre-opening power supply of power amplifier. Support silent intensity preset reduce function, support background accompaniment preset function.
remote control of the Internet of things on and off.
Support 15KVESD protection, built-in network isolation lightning protection processing circuit. Built-in three-wire audio control strong cutting output interface, no DC24V strong cutting power supply, and no limit on the number of audio control; At the same time compatible with 4-wire audio controller, external +24V power supply. Standby power less than 3W, meeting the national environmental protection and energy saving certification standards.
Product Usage
-
-
Product usage introduction
-
1 channel EMC input interface, input emergency alarm voice and audio signal, with the highest priority input.
Built-in 1-channel audio signal auxiliary output interface, expandable external power amplifier, industrial-grade terminal, fixed by screws, the connection reliability is much higher than that of conventional connector.Support mobile phone APP broadcast, play background music, intercom and other functions.
Support remote vod function, support 1000 level custom audio priority silent control (support multi-channel signal amplification, mixing, three-level priority control, tone adjustment).
-
Description of product use effect
Support DHCP, compatible with router, switch, gateway, Modem, Internet, 2G, 3G, 4G, multicast, unicast and other arbitrary network structure.
Support local IP configuration and remote login IP configuration scheme, the security factor is much higher than Web and other remote configuration scheme.
Authorized operation management function, support server unified configuration management user and password; Copy iOS tiled menu management, eliminate complex secondary menu.
Related Products
Packing&Shipping
We provide neutral standard packaging. Customized packaging can be customized.
Certifications
All product lines have passed the Compulsory Product Certification (3C Certification) of China Quality Certification Center, and have passed ISO9001 Quality Certification, ISO14001 Environmental Certification, ISO18001 Occupational Health Certification, Network Audio System Software Works Right certification, 2G/3G/4G wireless network voice broadcasting intercom system patent. The factory has passed SGS and Alibaba field certification. We also continue to meet all kinds of certification needs worldwide.
Company Introduction
XBPA is located in Shenzhen, a beautiful international metropolis in China. We are a research and development, production, marketing Audio equipment manufacturer integrating sales and service. Main business: public broadcast PA system, IP network intercom system, WIFI wireless network speaker series, 2G/3G/4G wireless voice broadcast system. Our audio system equipment is widely used in universities, middle schools, gymnasiums, supermarkets, parks, squares, Hotels, hotels, stations, docks, industrial and mining enterprises, garden communities, hospitals and other industries, play an irreplaceable role. Our aim is to make audio cover every corner of the world. Creating Subdivided and Targeted Achievements An audio system that can be used. With professional technology and perfect after-sales service, we will solve the problem of internal and external information transmission and broadcasting for customers all over the world. Since the product was introduced to the global market, it has been well received by many users due to its strong adaptability, simple operation, suitability for complex system design and many other excellent characteristics.
FAQ
Q: Can I buy the samples of audio power amplifier ?
A : yes , sample order are welcomed .
Q: What's the product warranty ?
A :12Months
Q : What's your factory quality control ?
A: ISO9001 quality control. CE, 3C approved . we test each speaker and amplifier one by one before leave factory . we Military sound system production factory
Q : When can you ship my order?
A : Normally 2days . for OEM order , 11-14days
Q : What Serivce can I get ?
A : Full Technique service supported. and offer you full quotation solution and diagram after you send us the project details and requirement.
