Quick Details
-
Mounting Type:
-
M9 nut
-
Description:
-
Magnetic proximity sensors
-
Model Number:
-
LSPS024-S/N
-
Place of Origin:
-
Japan
-
Brand Name:
-
LS
-
Theory:
-
Hall IC
-
Output:
-
15mA MAX
-
Product name:
-
Magnetic proximity sensors
-
Magnetic sensitivity:
-
Refer to below
-
Direction to detect:
-
Forward
-
Output curren:
-
15mA Max
-
Cable specifications:
-
2.8 3wire, Gray 1m
-
Nut material:
-
Brass
-
Mounting:
-
M9 nut tightening torpue 0.5N m
-
Indicator light:
-
Red
-
Protective structure:
-
IP67
-
Output specifications:
-
NPN open collector
Quick Details
-
Use:
-
response to the magnetic field
-
Series:
-
LS
-
Features:
-
high-accuracy response Higher sensitivity
-
Mounting Type:
-
M9 nut
-
Description:
-
Magnetic proximity sensors
-
Model Number:
-
LSPS024-S/N
-
Place of Origin:
-
Japan
-
Brand Name:
-
LS
-
Theory:
-
Hall IC
-
Output:
-
15mA MAX
-
Product name:
-
Magnetic proximity sensors
-
Magnetic sensitivity:
-
Refer to below
-
Direction to detect:
-
Forward
-
Output curren:
-
15mA Max
-
Cable specifications:
-
2.8 3wire, Gray 1m
-
Nut material:
-
Brass
-
Mounting:
-
M9 nut tightening torpue 0.5N m
-
Indicator light:
-
Red
-
Protective structure:
-
IP67
-
Output specifications:
-
NPN open collector
Product Description
Specification
|
Sensing pole
|
LSPS024:S-pole
|
|
|
LSPS024N:N-pole
|
|
Magnetic sensitivity
|
2.5～3.5mT
|
|
Magnetic sensitivity
|
|
|
Direction to detect
|
Forward
|
|
|
|
|
Output specifications
|
open collector(When proximity is turned ON)
|
|
Output current
|
15mA Max
|
|
Consumption current
|
8mA Max
|
|
Cable specifications
|
S-pole:φ2.8 3wire,Gray 1m
|
|
Cable specifications
|
N-pole:φ2.8 3wire,Black 1m
|
|
Case materials
|
GF reinforced PBT:Black
|
|
Nut material
|
Brass
|
|
Mounting
|
M9 nut tightening torque 0.5N･m
|
|
Mounting hole processing deimensions
|
φ9 0+0.5
|
|
Indicator light
|
Red
|
|
Protective structure
|
IP67
|
･Cable ectension are possible.
