Quick Details
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Online support
-
Product name:
-
high quality electric hoist
-
Color:
-
Customized
-
Power supply:
-
380V 50Hz Three-phase
-
Lifting height:
-
6/12m
-
Application:
-
Lifting Goods
-
Control Method:
-
Pendant +Remote(Customized)
-
Working Class:
-
A3-A5
-
Name:
-
Wire Rope Electric Hoist Crane
-
Type:
-
Liftling Equipment
-
Voltage:
-
220V
-
Certification:
-
CE,ISO,CCC
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Henan, China
-
After Warranty Service:
-
Video technical support, Online support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Online support
-
Product name:
-
high quality electric hoist
-
Color:
-
Customized
-
Power supply:
-
380V 50Hz Three-phase
-
Lifting height:
-
6/12m
-
Application:
-
Lifting Goods
-
Control Method:
-
Pendant +Remote(Customized)
-
Working Class:
-
A3-A5
-
Name:
-
Wire Rope Electric Hoist Crane
-
Type:
-
Liftling Equipment
-
Voltage:
-
220V
-
Certification:
-
CE,ISO,CCC
| Plug Type | EU Plug | |
| Rated Voltage | 220V AC | |
| Input Power | 450W | |
| Main Material | Steel | |
| Cable Diameter | 4.2mm | |
| IP Rating | IP54 | |
| Quantity | 1 | |
| Size | 34*13.3cm/13.4*5.2in | |
| Weight | 10kg(approx.) | |
| Using Method | Single-hook | Double-hook |
| Rated Lifting Weight | 100kg | 200kg |
| Lifting Speed | 10m/min | 5m/min |
| Lifting Height | 12m | 6m |
| Model | Capacity | Lifting height | Lifting speed | Voltage | Power | Packing Size | PCS/Case | N.W.(kg) |
| (kg) | (m) | (m/min) | (v) | r(Kw) | (cm) | |||
| PA200 | 100/200 | 12/6m | 10/5m/min | 220/230 | 0.51 | 47*37*16 | 2 | 22 |
| PA400 | 200/400 | 12/6m | 10/5m/min | 220/230 | 0.98 | 47*37*16 | 2 | 33 |
| PA600 | 300/600 | 12/6m | 10/5m/min | 220/230 | 1.2 | 47*37*16 | 2 | 33 |
| PA800 | 400/800 | 12/6m | 10/5m/min | 220/230 | 1.3 | 52*45*17.5 | 2 | 37 |
| PA1000 | 500/1000 | 12/6m | 10/5m/min | 220/230 | 1.6 | 51.5*34*19 | 1 | 32 |
Advantage and feature of PA electric hoist:
1.It can be used in factories, mines, agriculture, electric power. Construction building site, dock and warehouse for installation of the machines, lifting the cargoes. Loading and unloading the trucks.
2.The product we produced is in compliance with the national standard.
3.The design is reasonable
4.The materials are of good quality,
5.The structure is advanced.
6.The appearance is beautiful and the size is compact,
7.the weight is light, the hand pull force is small and parts have high strength,big tenacity, and all these make it safe durable.
8.The products are popular at home and abroad.
