Quick Details
-
Power:
-
25kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LTMG
-
Maximum Digging Height:
-
2600mm
-
Maximum Digging Depth:
-
1715mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
3065mm
-
Rated Speed:
-
2 km/h
-
Length:
-
2840mm
-
Max digging height:
-
2600mm
-
Max. digging width:
-
1715mm
-
Max. dumping height:
-
1830mm
-
Fuel Tank Capacity:
-
26L
-
Engine:
-
KOOP
-
Color:
-
Customizable
Quick Details
-
Operating Weight:
-
0.8Ton, 0.8t/1t/1.2t/1.5t/1.7t/2t
-
Bucket capacity:
-
0.023m³
-
Engine Brand:
-
KOOP
-
Power:
-
25kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LTMG
-
Maximum Digging Height:
-
2600mm
-
Maximum Digging Depth:
-
1715mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
3065mm
-
Rated Speed:
-
2 km/h
-
Length:
-
2840mm
-
Max digging height:
-
2600mm
-
Max. digging width:
-
1715mm
-
Max. dumping height:
-
1830mm
-
Fuel Tank Capacity:
-
26L
-
Engine:
-
KOOP
-
Color:
-
Customizable
2. Compared with the traditional diesel power mini excavator, the use of electric hydraulic system has the characteristics of saving energy, low noise, no exhaust pollution and high efficiency. It is more suitable for underground use, because electric power is used as power to save nearly half of the operation cost compared with the same type of diesel excavator.
3. Compared with the diesel drive, it overcomes the disadvantages of low temperature starting and high altitude, it can play an excellent performance in high altitude and low temperature environment with low temperature and radiation related configuration.
4. The machine is with compact structure, small size, small component parts and easy to use in vertical shaft. With the minimum rotating structure, the tail will not exceed the width of the machine when the body turns, so it is more suitable for the narrow space operation in the underground.
Details Images
Product Paramenters
|
Model
|
|
LTN08
|
LTN09
|
LTN10
|
|
Self Weight
|
kg
|
750
|
750kg
|
950kg
|
|
Bucket capacity
|
m³
|
0.02
|
0.02
|
0.025
|
|
Power
|
kw
|
koop 7.6kw
|
Lithium
|
Lithium
|
|
Wheel base
|
mm
|
420
|
420
|
770
|
|
Overall length
|
mm
|
2480
|
2480
|
2550
|
|
Overall height
|
mm
|
1250
|
1250
|
1330
|
|
Max. digging radius
|
mm
|
2050
|
2050
|
2400
|
|
Max. digging depth
|
mm
|
1200
|
1200
|
1650
|
|
Max. digging height
|
mm
|
2350
|
2350
|
2490
|
|
Max. dumping height
|
mm
|
1600
|
1600
|
1750
|
|
Model
|
|
LTN15
|
LTN17
|
LTN20
|
|
Self Weight
|
kg
|
1100
|
1350
|
2000kg
|
|
Bucket capacity
|
m³
|
0.04
|
0.03
|
0.045
|
|
Power
|
kw
|
ChangchaiEV80
|
Changchai390
|
Lithium
|
|
Wheel base
|
mm
|
800
|
1100
|
820
|
|
Overall length
|
mm
|
2680
|
2780
|
2830
|
|
Overall height
|
mm
|
1950
|
2200
|
2270
|
|
Max. digging radius
|
mm
|
2900
|
2400
|
3700
|
|
Max. digging depth
|
mm
|
1850
|
1850
|
2150
|
|
Max. digging height
|
mm
|
2450
|
2740
|
3275
|
|
Max. dumping height
|
mm
|
1850
|
2400
|
2385
|
