Specifications
|
Dimension
|
80.5 mm x 60 mm x 23.5 mm
|
Weight
|
100g
|
|
I/O power cable length
|
50 cm
|
Power supply
|
DC 9–90 V/1.5 A
|
|
Power consumption
|
Current in standby mode: 65 mA
|
Operating temperature
|
-35°C to 80°C (without battery)
|
|
Operating humidity
|
5% to 95%
|
LED indicator
|
Green indicator showing the GSM signal
Blue indicator showing the GPS signal |
|
Button/Switch
|
1 upgrade button
1 power button |
Memory
|
8 MB buffer
|
|
Sensor
|
3-axis accelerometer
|
Microphone/Speaker
|
External (optional)
|
|
GPS sensitivity
|
-165 dB
|
Positioning accuracy
|
2.5m
|
|
I/O port
|
2 digital inputs and 1 analog detection input (0–30 V; selectable positive, negative, and analog detection inputs)
1 output 1 USB port 1-Wire® iButton 1-Wire® temperature sensor 1 output (voltage: 5V) 1 RS232 port (T366 RS232 version): GND/TX/RX |
Frequency band
|
T366
GSM 850/900/1800/1900 MHz T366L T366L-E: LTE FDD:B1/B3/B5/B7/B8/B20, WCDMA: B1/B5/B8, GSM/GPRS: B3/B8 T366L-A: LTE FDD:B2/B4/B12, WCDMA: B2/B4/B5 T366L-AU: LTE FDD:B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD:B40, WCDMA: B1/B2/B5/B8, GSM/GPRS: B2/B3/B5/B8 T366L-AUT:LTE FDD:B1/B3/B5/B7/B28, WCDMA: B1/B5 |
Accessories
|
ACCESSORIES
|
T366 Series tracker
|
L wrench
|
Hexagon screw
|
|
|
CD download card
|
|
|
|
OPTIONAL ACCESSORIES
|
A52 digital temperature sensor
|
A53 fuel level sensor
|
A57 speaker
|
|
|
A58 microphone
|
A64 remote control receiver
|
A67 remote control USB cable
|
|
|
400 mAh battery
|
External GPS antenna
|
Ultrasonic fuel level sensor
|
|
|
LED display
|
USB cable
|
RFID
|
|
|
Buzzer
|
iButton reader
|
Relay (12 V/24 V)
|
|
|
A89 driver fatigue monitor
|
|
|
