Quick Details
-
Product name:
-
Insulated cord end terminals
-
Color:
-
red / grey /Blue
-
Material of terminal:
-
Copper
-
Insulating material:
-
PP
-
wire size:
-
10mm2
-
Certificated:
-
CE
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
MG
-
Model Number:
-
E4018
-
Product name:
-
Insulated cord end terminals
-
Color:
-
red / grey /Blue
-
Material of terminal:
-
Copper
-
Insulating material:
-
PP
-
wire size:
-
10mm2
-
Certificated:
-
CE
Insulated cable cord electric wire boot laceferrule copper tube terminals
| Model Numble | E |
| Product Name | Best Price Insulated Dumb Electric Wire Cord End Terminals |
| Certificate |
SGS,CE,RoHS,ISO9001 |
| Material |
Insulation:P.P Terminal Body:Copper Plating:Tin |
| Color | Red,Blue and Yellow |
| Wire size | 0.5-1.5mm 2 , 1.5-2.5 mm 2 ,2.5-4 mm 2 ,4-6mm 2 , |
| Product Feature |
1.Easy to use,Insulated 2.High quality and high purity copper |
| Packing |
100Pcs/Bag |
| Application |
Electricity, communications, machinery, construction, petroleum, chemical, aviation, transportation,railway, transportation, automobile manufacturing, household appliances,electrical installations,computers etc. |
| Function | Electrically conduction and connection |
| Port of Shipment | Ningbo or Shanghai |
| Delivery Time | Shipped in 7 days it depend on your order |
|
OEM/ODM |
Available |
|
Payment |
T/T,L/C,Western Union,PayPal |
| ITEM NO. | Dimension(mm) | Conductor section | Color of insulation sheath | |||||
| F | L | W | D | C | A.W.G | mm2 |
(Top)Germany
(Bottom)France |
|
| E0505 | 5 | 11 | 2.5 | 1.3 | 1 | 22 | 0.5 | White |
| E0506 | 6 | 12 | ||||||
| E0508 | 8 | 14 | Orange | |||||
| E0510 | 10 | 16 | ||||||
| E0512 | 12 | 18 | ||||||
| E7506 | 6 | 12.4 | 2.8 | 1.5 | 1.2 | 20 | 0.75 | Blue |
| E7508 | 8 | 14.6 | ||||||
| E7510 | 10 | 16.4 | White | |||||
| E7512 | 12 | 18.4 | ||||||
| E7518 | 18 | 24.4 | ||||||
| E1006 | 6 | 12.4 | 3 | 1.7 | 1.4 | 18 | 1 | Red |
| E1008 | 8 | 14.6 | ||||||
| E1010 | 10 | 16.4 | Yellow | |||||
| E1012 | 12 | 18.4 | ||||||
| E1018 | 18 | 24.4 | ||||||
| E1508 | 8 | 14.6 | 3.5 | 2 | 1.7 | 16 | 1.5 | Black |
| E1510 | 10 | 16.4 | ||||||
| E1512 | 12 | 18.4 | Red | |||||
| E1515 | 15 | 21.4 | ||||||
| E1518 | 18 | 24.4 | ||||||
| E2508 | 8 | 15.2 | 4 | 2.6 | 2.3 | 14 | 2.5 | Grey |
| E2510 | 10 | 17.2 | ||||||
| E2512 | 12 | 19.2 | Blue | |||||
| E2518 | 18 | 25.2 | ||||||
| E2525 | 25 | 32.2 | ||||||
| E4009 | 9 | 16.5 | 4.4 | 3.2 | 2.8 | 12 | 4 | Orange |
| E4010 | 10 | 17.5 | ||||||
| E4012 | 12 | 19.5 | Grey | |||||
| E4018 | 18 | 25.5 | ||||||
| E6012 | 12 | 20 | 6.3 | 3.9 | 3.5 | 10 | 6 | Green |
| E6018 | 18 | 26 | Black | |||||
| E10-12 | 12 | 21.5 | 7.6 | 4.9 | 4.5 | 8 | 10 | Brown |
| E10-18 | 18 | 27.5 | Lvory | |||||
| E16-12 | 12 | 22.2 | 8.8 | 6.2 | 5.8 | 6 | 16 | Lvory |
| E16-18 | 18 | 28.2 | Green | |||||
| E25-15 | 15 | 28 | 11.2 | 7.9 | 7.5 | 4 | 25 | Black |
| E25-16 | 16 | 29 | ||||||
| E25-18 | 18 | 31 | Brown | |||||
| E25-22 | 22 | 35 | ||||||
| E35-16 | 16 | 30 | 12.7 | 8.7 | 8.3 | 2 | 35 | Red |
| E35-18 | 18 | 32 | ||||||
| E35-22 | 22 | 36 | Beige | |||||
| E35-25 | 25 | 39 | ||||||
| E50-20 | 20 | 36 | 15.3 | 10.9 | 10.3 | 1/0 | 50 | Blue |
| E50-25 | 25 | 41 | Olive | |||||
| E70-20 | 20 | 37 | 16 | 14.3 | 13.5 | 3/0 | 95 | Yellow |
| E70-25 | 25 | 42 | ||||||
| E70-27 | 27 | 44 | ||||||
| E95-25 | 25 | 44 | 18.5 | 15.3 | 14.5 | 3/0 | 95 | Red |
| E120-27 | 27 | 47.6 | 20.3 | 17.5 | 16.5 | 4/0 | 120 | Blue |
| E120-32 | 32 | 52.6 | ||||||
| E150-25 | 25 | 50.6 | 23.4 | 20.6 | 19.6 | 250/300 | 150 | Yellow |
| E150-27 | 27 | 52.6 | ||||||
| E150-32 | 32 | 57.6 | ||||||
