Quick Details
-
Charging Port:
-
No
-
Connection:
-
32A European standard plug
-
Combination:
-
Follow vehicle lock, LED indicator light, Start by swiping card
-
Voltage:
-
230v
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
EV, Can be customized
-
Model Number:
-
ZR-EUO10-4
-
Design Style:
-
modern
-
Product name:
-
ZR-EUO10-4 V8 screen display wall-mounted column-type AC Charging pile
-
Application:
-
AC Household wall-mounted
-
Color:
-
navy blue, dark blue, silver white
-
Current:
-
32 Amp
-
Power:
-
7KW
-
Standby Power:
-
3W
-
Cable length:
-
5 Meters, can be customized
-
Installation:
-
column /wall-mounted
-
Package size:
-
530*470*220mm , 1pcs/CTN
Quick Details
-
Function:
-
Colorful lights, screen display, Signal Stabilization, Voltage Monitoring, LED indicator light, Intelligent temperature control, follow car lock
-
Car Fitment:
-
JAC YTTRIUM IS, Adly Moto, LEXUS(EU), Opel - Europe, Baw, Seat LCV - Europe Van, HONDA(US), Ford - Europe, Foden - Europe, GYON
-
Type:
-
Wall Charger, wired charging, Swipe card, column-type
-
Charging Port:
-
No
-
Connection:
-
32A European standard plug
-
Combination:
-
Follow vehicle lock, LED indicator light, Start by swiping card
-
Voltage:
-
230v
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
EV, Can be customized
-
Model Number:
-
ZR-EUO10-4
-
Design Style:
-
modern
-
Product name:
-
ZR-EUO10-4 V8 screen display wall-mounted column-type AC Charging pile
-
Application:
-
AC Household wall-mounted
-
Color:
-
navy blue, dark blue, silver white
-
Current:
-
32 Amp
-
Power:
-
7KW
-
Standby Power:
-
3W
-
Cable length:
-
5 Meters, can be customized
-
Installation:
-
column /wall-mounted
-
Package size:
-
530*470*220mm , 1pcs/CTN
ZR-EUO10-4 V8 screen display wall-mounted column-type AC Charging pile with LCD 4.3-inch display and LED indicator light
Product Details
Product Description
|
Item Name
|
ZR-EUO10-4 V8 screen display wall-mounted column-type AC Charging pile with LCD 4.3-inch display and LED indicator light
|
|
|
|
|||
|
Product features
|
Household wall-mounted AC charging pile, can be installed with a column, Start by swiping card, with LED indicator light and LCD 4.3-inch display
|
|
|
|
|||
|
color
|
Three color shells are available, navy blue, black, white
|
|
|
|
|||
|
Input voltage
|
AC230V
|
|
|
|
|||
|
Max power
|
7KW
|
|
|
|
|||
|
Cable length
|
5m,Can be customized
|
|
|
|
|||
|
Standard Code
|
ZR-EUO10-4
|
|
|
|
|||
|
Output current
|
32A
|
|
|
|
|||
|
LED indicator light
|
The three-color charging indicator light displays the numerical value on the screen, prompting charging related numerical values.
|
|
|
|
|||
|
Install
|
Column type/wall-mounted type, with wall-mounted screw accessories/fixed washers [can be installed with columns]
|
|
|
|
|||
|
Wire specification
|
3*6MM
2
+ 0.75MM
2
|
|
|
|
|||
|
Working temperature
|
-30℃~+50℃
|
|
|
|
|||
|
Applicable scene
|
Indoor/outdoor
|
|
|
|
|||
|
Product Size
|
Charger gun head 230*98*70mm, pile box 300*220*80mm [H*W*D]
|
|
|
|
|||
|
Shell material
|
Charger gun head, pile box PC9330
|
|
|
|
|||
|
Protection level
|
Charger Gun head IP67/Control box IP54
|
|
|
|
|||
|
Safety standard
|
IEC62196-2
|
|
|
|
|||
|
Flame retardant grade
|
UL94V0
|
|
|
|
|||
|
Product certification
|
TUV, CE, ROHS, CB
|
|
|
|
|||
|
Safe Design
|
*Undervoltage protection, *Overvoltage protection, *Overload protection, *Overcurrent protection, *Overtemperature protection,
*Leakage protection, *Grounding protection, *Lightning protection, *Electrostatic protection, *Flame retardant protection,
*Follow vehicle lock
|
|
|
|
|||
|
Equipment weight
|
About 6KGS
|
|
|
|
|||
