Quick Details
-
Storage Type:
-
15°C~25°C
-
The charging ratio:
-
0.25C
-
The discharge rate:
-
30l.A(3min)
-
Warranty:
-
1 year
-
Brand Name:
-
Sunwave
-
Model Number:
-
6-GFM-100-250AH
-
Place of Origin:
-
Hefei
-
Weight:
-
55.5KG
-
Electric Energy:
-
3000 Wh
-
Product name:
-
Lead-acid Maintenance-free Battery
-
Type:
-
Acid Lead Battery
-
Usage:
-
Slolar Energy System
-
Rated voltage:
-
12V
-
Capacity (10hr,1.80v/Cell):
-
200Ah
-
Recommended Using temperature:
-
15°C~25°C
-
Cover Material:
-
ABS
-
Capacity Affected byTemperature:
-
105% @ 40°C
-
Charging Mode (25°C):
-
Float Charge: 2.275±0.025V/Cell
-
Color:
-
White
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
Gel
-
Cycle Life:
-
50%D0D 1422 times
-
Storage Type:
-
15°C~25°C
-
The charging ratio:
-
0.25C
-
The discharge rate:
-
30l.A(3min)
-
Warranty:
-
1 year
-
Brand Name:
-
Sunwave
-
Model Number:
-
6-GFM-100-250AH
-
Place of Origin:
-
Hefei
-
Weight:
-
55.5KG
-
Electric Energy:
-
3000 Wh
-
Product name:
-
Lead-acid Maintenance-free Battery
-
Type:
-
Acid Lead Battery
-
Usage:
-
Slolar Energy System
-
Rated voltage:
-
12V
-
Capacity (10hr,1.80v/Cell):
-
200Ah
-
Recommended Using temperature:
-
15°C~25°C
-
Cover Material:
-
ABS
-
Capacity Affected byTemperature:
-
105% @ 40°C
-
Charging Mode (25°C):
-
Float Charge: 2.275±0.025V/Cell
-
Color:
-
White
Product Descriptions
Feature
*The electrolyte adopts nano-colloid technology, which has better wide temperature adaptability, avoiding thermal runaway and ensuring the reliability and safety of the battery.
*Unique active substance formula and proprietary Pb-Ca alloy process minimise grid corrosion, reduce gas emission and extend battery life.
*Excellent low temperature performance and charging acceptance
*Special electrolyte additives to prevent short-circuiting of lead dendrites and storage passivation.
*Good deep cycle performance and strong recovery ability after deep discharge.
Product Specifications
|
Ratec voltage
|
12V
|
|
Capacity(10hr,1.80V/Cell)
|
200Ah
|
|
Weight
|
55.5Kg
|
|
Max discharge current
|
30l₁₀A(3min)
|
|
Cover Material
|
ABS
|
|
Max charging current
|
≤0.25C₁
|
|
Self-discharge (25℃)
|
≤3%/month
|
|
Recommendec Using temperature
|
15°C~25℃
|
|
|
Discharge:-45°C~50°C
|
|
|
Charge:-20°C~45°C
|
|
|
Storage:-30°C~40°C
|
|
|
floating charge:13.5V-13.8V
|
|
|
equalizing charge: 14.1V-14.4V
|
|
|
Float Charge: 2.275±0.025V/Cell
Temperature parameters:±3mV/Cell C
|
|
|
Cycle Charge: 2.45±0.05V/Cell
Temperature Compensation Coefficient: ±5mV/Cell C
|
|
Cycle life
|
100%D0D 572 times
|
|
|
50%D0D 1422 times
|
|
|
30%00D 2218 times
|
|
Capacity Affected by Temperature
|
105% @ 40°C
|
|
|
90% @ 0°C
|
|
|
70% @-20°C
|
