Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WZLC
-
Weight:
-
1 KG
-
Dimension(L*W*H)::
-
Customized
-
Power(W):
-
costumized
-
Certification:::
-
CE ISO9001 ROHS
-
Voltage::
-
costumized
-
Application:
-
injection molding machine
-
Insulation material:
-
MGO
-
Tube material:
-
6MM 8MM 10MM 12MM 14MM 16MM 20MM
-
MOQ:
-
1 Pcs
Quick Details
-
Type:
-
Immersion Heater
-
Power Source:
-
Electric
-
Voltage:
-
CUSTOMIZED
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WZLC
-
Weight:
-
1 KG
-
Dimension(L*W*H)::
-
Customized
-
Power(W):
-
costumized
-
Certification:::
-
CE ISO9001 ROHS
-
Voltage::
-
costumized
-
Application:
-
injection molding machine
-
Insulation material:
-
MGO
-
Tube material:
-
6MM 8MM 10MM 12MM 14MM 16MM 20MM
-
MOQ:
-
1 Pcs
Specifications
1)Resistance wire OCr20Ni80,
2)Min.dia.3mm,length:30mm.
3)high density cartridge heater.
4)ss304/316 sheath.
5)10~25w/cm
High Temperature Resistance Cartridge Heater
Cartridge heater is cylindrical electrical heating elements. Protected with a stainless steel sh Cartridge heater with right angle and hose eath, their watt density can reach 25 W/cm2 and their operating temperature can go up to 800°C (1472°F)
Mostly cartridge heat Cartridge Heater Pipe Solar Water Heater er is used for heating up solids such as injection presses heating plates or various tools, cartridge heater can also be used for heating up water of gases under certain conditions. Widely used for manufacturing plastic and rubber parts in the car industry or in the food processing industry, etc . cartridge heaters are also commonly found in the chemical, electronics, , packing and nuclear industries
Various cartridge heater technologies are available. The choice of technology will depend on technical specifications required and the application. Unless you know exactly which product you are looking for, we will recommend you the best solution for your needs.
Technical Detail:
|
Heat intensity |
Not exceeding 30Wcm2 (advisable) |
|
Power |
Depends on the dimension |
|
Escape of current (when cold) |
<=0.1mA a 242 v. |
|
Insulation (when cold) |
5 Min Ohmios 500 Watts minimum |
|
Dielectric strength |
1500v. 1/seg |
|
Working temperature |
750ºG max. |
|
Tolerance of length |
+/-1.5% |
|
Tolerance of diameter |
-0.01 a -0.06 m/m |
|
Tolerance of cut of connexion |
+/-15 mlm |
|
Power tolerance (w) |
5 % - 10 % |
|
Cold areas |
Depends on length and diameter 5-25mm |
Feature:
Commom cartridge can be devideded :
1) High power density (heat area sufuce power 10~25w/cm2)
Working temperature≤450 degrees.
2) Middle,low power density (heat area sufuce power 5~11/cm2)
working temperature≤ 300 degrees
Votage:12~250V (or as requirment)
High Density Construction
High-quality stainless steel construction provides long-lasting protection even in the most rugged industrial environments
Protected with a stainless steel sheath, their watt density can reach 50 W/cm2 and their operating temperature can go up to 800°C.
CAN COSMIZED ACCORDING TO COSTUMER’S REQUIREMENT \
