Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
OEM
-
Model Number:
-
LS-AHD2021
-
Technology:
-
Infrared and waterproof
-
Resolution:
-
5MP
-
Product name:
-
ahd 5mp ahd tvi cctv camera
-
Lens:
-
3.6mm 2.8mm 6mm optional
-
Keyword:
-
Wired P2p Cctv ahd Camera
-
Feature:
-
P2P Cloud and night vision, waterproof
-
Image Sensor:
-
1/2.7" 2MP sony CMOS
-
IR Distance:
-
40M
Quick Details
-
Special Features:
-
Waterproof / Weatherproof
-
Function:
-
NIGHT VISION
-
Customized support:
-
Customized logo, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
OEM
-
Model Number:
-
LS-AHD2021
-
Technology:
-
Infrared and waterproof
-
Resolution:
-
5MP
-
Product name:
-
ahd 5mp ahd tvi cctv camera
-
Lens:
-
3.6mm 2.8mm 6mm optional
-
Keyword:
-
Wired P2p Cctv ahd Camera
-
Feature:
-
P2P Cloud and night vision, waterproof
-
Image Sensor:
-
1/2.7" 2MP sony CMOS
-
IR Distance:
-
40M
Product Description:
Main Features:
1. Analog High Definition;
2. BNC interface, connect normal coaxial cable up to 500M;
3. Real-time transmission,no delay;
4. Support UTC function,control camera in DVR menu via coxial cable;
5. Support IR-CUT auto-switch;
6. Software supports TVI-AHD-CVI-CVBS 4 in 1.
7. Power adapter not included
| Model NO. | LS-2021AHD |
| Camera | |
| Image Sensor | 1/2.7" CMOS |
| Image Resolution | 5MP |
| Effective Pixels | 1920*1080 |
| Video Format | PAL/NTSC |
| Electronic Shutter | 1/25s~1/50,000s , 1/30s~1/60,000s |
| Sync System | Internal |
| Usable Illumination | 0.001Lux |
| S/N Ratio | ≥50dB |
| Scanning System | Progressive Scan |
| Video Output Mode | CVBS(BNC) |
| Transmission Distance | >500M (75-5 coaxial cable ) |
| Lens | |
| Focus Length | 2.8 / 3.6 / 4 / 6 / 8 / 12mm Optional |
| Focus Control | Fixed |
| Pixels | 3MP Pixels |
| Auto Iris Support | NO |
| Night Vision | |
| Infrared LED | 6pcs IR Leds |
| Infrared Distance | 40M |
| IR Status | Under 10 Lux by CDS |
| IR Power On | CDS Auto Control |
| Day/Night | Auto (ICR) / Color / B&W |
| Camera Features | |
| OSD Menu Language | EN, CN, DE, FRA, IT, ES, PL, RU, PT, NL, TR, etc… |
| White Balance | Auto/Manual |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Picture Adjustment | Yes |
| OSD Support | Optional |
| General | |
| Material | Metal, IP66 |
| Color | White |
| IR Cut Filter | YES |
| Operation Temperature | -10℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 1000mA |
| Dimension | Φ60×120mm |
| Weight | 0.3Kg |
| General | |
| Power supply | DC12V±10% |
| Working Environment | -30℃~+60℃/Less than 95%RH(no condensation) |
| Transmission Distance | Over 500M via 75~3 Coaxial Cable |
