Quick Details
-
Brand Name:
-
NMPC
-
Standard or Nonstandard:
-
Standard
-
Working pressure:
-
0~1.0MPa
-
Product name:
-
solenoid valve 2W025-08
-
orifice size:
-
2.5mm
-
joint pipe bore:
-
G1/4, G3/8, G1/2, G3/4, G1, G2
-
working medium:
-
air water oil gas
-
standard voltage:
-
DC12V DC24V AC24V AC110V AC220V
-
operating temperature:
-
-5~80
-
material of body:
-
brass
-
material of oil seal:
-
NBR OR EPDM
Quick Details
-
Port Size:
-
G1/8' ,G1/4",G3/8'
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
2W
-
Brand Name:
-
NMPC
-
Standard or Nonstandard:
-
Standard
-
Working pressure:
-
0~1.0MPa
-
Product name:
-
solenoid valve 2W025-08
-
orifice size:
-
2.5mm
-
joint pipe bore:
-
G1/4, G3/8, G1/2, G3/4, G1, G2
-
working medium:
-
air water oil gas
-
standard voltage:
-
DC12V DC24V AC24V AC110V AC220V
-
operating temperature:
-
-5~80
-
material of body:
-
brass
-
material of oil seal:
-
NBR OR EPDM
|
|
Thread Option: G and NPT
Standard Voltage Option: DC12V,DC24V,AC110V,AC220V
Material Option: Brass and Stainless Steel
Oil Seal Option:NBR,EPDM,VITON
normally closed 12v gas solenoid valve
|
Model |
2W025-08 |
|
Fluid |
Air, Water, Oil, Gas |
|
Operation |
Direct Drive Type |
|
Type |
Normal Close Type |
|
Aperture of flow rate |
2.5 |
|
Cv value |
0.23 |
|
Port size |
G1/4(Option:NPT1/4'') |
|
Operation fluid viscosity |
20 CST Below |
|
Operation pressure |
0 ~ 0.7MPa |
|
Max.Proof pressure |
1.0MPa |
|
Operation temperature |
-5 ~ +80C |
|
Voltage |
DC12V(Option:AC110V,220V, DC24V) |
|
Voltage range |
±10% |
|
Metarial of body |
2W: Brass (Option:2S: Stainless Steel) |
|
Material og oil seal |
NBR (Option:EPDM or VITON) |
