Quick Details
-
Size:
-
Designed, 2.1m*3.6m*3m
-
Material:
-
stainless steel
-
Warranty:
-
1 year
-
Design Style:
-
Common
-
Voltage:
-
380V 50Hz
-
MOQ:
-
1set
-
Water consumption:
-
120 liters/car
-
Washing Speed:
-
2-4 minutes
-
Car wash:
-
10ml/car
-
Style:
-
common
-
machine movement speed:
-
8.5m/min
-
Product name:
-
Automatic Car Wash Machine
-
Color:
-
Customer's Request
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hai Ze
-
Model Number:
-
HZ-5LMF
-
Size:
-
Designed, 2.1m*3.6m*3m
-
Material:
-
stainless steel
-
Warranty:
-
1 year
-
Design Style:
-
Common
-
Voltage:
-
380V 50Hz
-
MOQ:
-
1set
-
Water consumption:
-
120 liters/car
-
Washing Speed:
-
2-4 minutes
-
Car wash:
-
10ml/car
-
Style:
-
common
-
machine movement speed:
-
8.5m/min
-
Product name:
-
Automatic Car Wash Machine
-
Color:
-
Customer's Request
Product Description
Specification
|
Car Washing Machine Parameters
|
|
|
|
|
||||
|
Project
|
|
Parameters
|
Remark
|
|
||||
|
car wash speed
|
|
2-4 minutes
|
According to different modes
|
|
||||
|
car wash water consumption
|
|
120 liters/car
|
Average number of different models
|
|
||||
|
Car wash power consumption
|
|
0.5
degrees/vehicl
e
|
Average number of different models
|
|
||||
|
Maximum car wash height
|
|
2100
|
Unit: mm
|
|
||||
|
Maximum car wash width
|
|
2200
|
Unit: mm
|
|
||||
|
Maximum car wash length
|
|
5500
|
Unit: mm
|
|
||||
|
machine movement speed
|
|
8.5m/min
|
Frequency
|
|
||||
|
Installed power
|
|
24KW
|
All electrical equipment power
|
|
||||
|
Installed voltage
|
|
380V/50Hz
|
Three-phase five-wire system, 10 square international cable
|
|
||||
|
Equipment size
|
|
Length 2.1m Width 3.6m Height 3m
|
Unit: m
|
|
||||
|
Installation size
|
|
10m long, 4m wide, 3.2m high (excluding the reserved space for import and export vehicles)
|
Unit: m
|
|
||||
|
car wash
|
|
10ml/car
|
|
|
||||
|
Car wash equipment function introduction table
|
|
|
|
|
||||
|
Main body configuration system Reciprocating car washing machine
|
|
|
|
|
||||
|
The main frame of the whole machine hot-dip galvanized sheet
|
|
|
|
|
||||
|
Modular design, tenon-and-mortise structure
|
|
|
Coupling conversion transition drive system
|
Special thick bearing, precision transmission chain
|
||||
|
International famous brand electric and gas system control center
|
|
|
|
|
||||
|
Triple photoelectric protection 180-degree tactile anti-collision technology
|
|
|
|
|
||||
|
22KW fixed air drying fan
|
|
|
Scan code for car wash payment, voice guidance
|
|
||||
|
Intelligent variable frequency speed control
|
|
|
Siphon liquid supply control system (foam, water-wax ratio)
|
|
||||
|
High-definition large-screen embedded touch-screen operation interface (central control and operating system)
|
|
|
|
|
||||
|
American Banner Photoelectric Detection
System
|
|
|
High performance waterproof motor, reducer
|
|
||||
|
Silent stainless steel high pressure centrifugal pump
|
|
|
Stainless Steel Waterproof Sealed Walking Wheel
|
|
||||
|
Intelligent copy current top brush system
|
|
|
Compression and flexible high pressure water pipe
|
|
||||
|
Signal lights and display systems
|
|
|
Winter antifreeze drainage function
|
|
||||
|
Free switching function of various cleaning
modes
|
|
|
Upper and lower floor independent split design
|
|
||||
|
Automatic high pressure water system
|
|
|
self-protection system, Fault alarm system, Machine emergency stop system
|
|
||||
|
Chainless gear drive vertical brush
system
|
|
|
High-quality anti-kneading tube wire/stainless steel fittings
|
|
||||
Device model
Packing & Delivery
We are based on customers' requirement.
